BrightSign HD226 Single UHD Video Decoder Digital Signage Player - GPIO - Analog Audio Output

HD226 - Overview

• Features:

  • Delivers impactful, smooth animations and dynamic visuals effortlessly and reliably, without a PC
  • Crafts engaging experiences by immersing all the senses and enabling interactive storytelling
  • Captures user-behavior data to deliver personalized experiences
  • Ensures dependable operation with a secure internal microSD or in any location with an optional LTE modem
  • Unparalleled reliability, security, and sustainability on BrightSignOS
  • Reduces the total cost of ownership with complementary remote player management and controls
  • Achieves CMS choice flexibility with a trusted global network of leading integrated partner solutions
  • Leverages an integrated Neural Processing Unit (NPU), enabling BrightSign players to run powerful AI applications without compromising on video or graphics performance


• Specifications:

  • Video I/O: 1x HDMI 2.0a Output
  • Audio I/O: 1x 3.5mm Line Input/Output
  • Media/Memory Card Single Slot: microSD (Unspecified Type)
  • Internal Storage: Yes
  • Other I/O:
    - 1x 3.5mm Port (IR)
    - 1x 12-pin Phoenix (4 GPIO)
    - 1x RJ45 (Gigabit Ethernet)
    - 1x RJ45 (10/100 Ethernet)
    - 1x M.2 E Key for Optional Wi-Fi/Bluetooth Module
    - 2x Wi-Fi Antennas
  • Power Source: Proprietary Interface (Built-In)
  • DC Input Power: 12VDC at 3A
  • Color: Black/Purple
  • Operating Conditions: 32°F - 122°F (0°C - 50°C)
  • Dimensions: 8.1" x 7.3" x 0.8" (205mm x 185.9mm x 19.2mm)
  • Weight: 1.3lbs (590g)


• GTIN:

  0854529008326
