Chauvet Ovation E-4WW IP Outdoor-Rated 3000K Warm White ERS-style DMX Light Fixture with Gel Frame - No Lens Tube

OVATION E-4WW IP - Overview

• Features:

  • Warm white ERS-style fixture with exceedingly bright output
  • Fully IP65 rated for seasonal use indoors or out
  • Use of Chauvet's standard Ovation beam shaping shutters and lenses lends familiarity and ease of use to the fixture
  • Ultra-smooth 16-bit dimming, and 8-bit dimming curves to complement any lighting scheme.
  • Flat, even field of light for superior gobo projection with tremendous color rendering
  • Dedicated power/data port for Ovation GR-1 Gobo Rotator


• Specifications:

  • Optical
  • Light Source: 1 LED (WW) 400W, 50,000 hours life expectancy
  • Color Temperature (at full): 3200 K
  • CRI: 97.8
  • Beam Angle (w/5° lens): 6.9°
  • Beam Angle (w/10° lens): 9.9°
  • Beam Angle (w/14° lens): 13.6°
  • Beam Angle (w/19° lens): 17°
  • Beam Angle (w/26° lens): 18.9°
  • Beam Angle (w/36° lens): 25.2°
  • Beam Angle (w/50° lens): 38.7°
  • Beam Angle (w/15°-30° lens)(Narrow): 12.3°
  • Beam Angle (w/15°-30° lens)(Wide): 20.1°
  • Beam Angle (w/25°-50° lens)(Narrow): 21.2°
  • Beam Angle (w/25°-50° lens)(Wide): 29.2°
  • Field Angle (w/5° lens): 9.3°
  • Field Angle (w/10° lens): 12.5°
  • Field Angle (w/14° lens): 16.6°
  • Field Angle (w/19° lens): 21°
  • Field Angle (w/26° lens): 27.1°
  • Field Angle (w/36° lens): 36.1°
  • Field Angle (w/50° lens): 53.1°
  • Field Angle (w/15°-30° lens)(Narrow): 17.1°
  • Field Angle (w/15°-30° lens)(Wide): 30.4°
  • Field Angle (w/25°-50° lens)(Narrow): 28.1°
  • Field Angle (w/25°-50° lens)(Wide): 41.4°
  • Dimming Modes: 4
  • Lumens (w/5° lens): 13,989
  • Lumens (w/10° lens): 16,250
  • Lumens (w/14° lens): 17,524
  • Lumens (w/19° lens): 16,766
  • Lumens (w/26° lens): 21,213
  • Lumens (w/36° lens): 21,219
  • Lumens (w/50° lens): 20,831
  • Lumens (w/15°-30° lens)(Narrow): 15,302
  • Lumens (w/15°-30° lens)(Wide): 19,171
  • Lumens (w/25°-50° lens)(Narrow): 21,049
  • Lumens (w/25°-50° lens)(Wide): 20,936
  • Selectable PWM: 600 Hz, 1,200 Hz, 2,000 Hz, 4,000 Hz, 6,000 Hz, 25KHz

    Dynamic Effects
  • Dimmer: Electronic
  • Shutter/Electronic
  • Strobe Rate: 0 to 30 Hz
  • Color Temperature Presets: No
  • Dim Modes: 4
  • Dim Curves: 4
  • Built-in Automated Programs: Yes

    Construction / Physical
  • Dimensions (fixture only): 19.5 x 11.2 x 19.2 in
  • Dimensions (w/5° lens extended): 40.4 x 14.5 x 19.2 in
  • Dimensions (w/10° lens extended): 32.2 x 12.4 x 19.2 in
  • Dimensions (w/14° lens extended): 28.9 x 11.9 x 19.2 in
  • Dimensions (w/19° lens extended): 26 x 11.9 x 19.2 in
  • Dimensions (w/26° lens extended): 26 x 11.9 x 19.2 in
  • Dimensions (w/36° lens extended): 26 x 11.9 x 19.2 in
  • Dimensions (w/50° lens extended): 26 x 11.9 x 19.2 in
  • Dimensions (w/15°-30° lens): 32.3 x 11.9 x 19.2 in
  • Dimensions (w/25°-50° lens): 25.1 x 11.9 x 19.2 in
  • Exterior Color: Black
  • Housing Material: Aluminum die-cast
  • Gobo Size (Optional): "A": 100 mm (outside), 75 mm (image), 2.5 mm (max. thickness)
  • Gobo Size (Optional): "B": 86 mm (outside), 64.5 mm (image), 2.5 mm (max. thickness)

    Connections
  • Power Connection: Edison (local) plug to Seetronic Powerkon IP65
  • Power Input: Seetronic Powerkon IP65
  • Power Output: Seetronic Powerkon IP65
  • Data Connectors: 5-pin XLR
  • Cable Length (power): 5 ft

    Control
  • Control Protocol: DMX, RDM
  • DMX Channels: 2, 3, 4, or 7
  • Modes/Personalities: 4 personalities (2, 3, 4, 7)

    Electrical
  • Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
  • Power Linking: 2 units @ 100 V; 3 units @ 120 V; 6 units @ 208 V; 6 units @ 230 V; 7 units @ 240 V
  • Power and Current: 433 W, 4.34 A @ 100 V, 60 Hz
  • Power and Current: 428 W, 3.57 A @ 120 V, 60 Hz
  • Power and Current: 416 W, 2.0 A @ 208 V, 60 Hz
  • Power and Current: 416 W, 1.81 A @ 230 V, 50 Hz
  • Power and Current: 413 W, 1.73 A @ 240 V, 60 Hz

    Certifications / Qualifications
  • CE, MET, UKCA, RoHS
  • IP Rating: IP65, temporary outdoor/wet use


• Item Includes:

  • 1x Ovation E-4WW IP
  • 1x Seetronic Powerkon IP65


• GTIN:

  0781462223960
