Crown DriveCore DCi 2/300N Install Network Series Two-Channel 300W @ 4 Ohm Audio Power Amplifier w/ BLU Link - 70V/100V

ITEM #: CROWN-DCI2X300NU MFG #: DCI2X300N-U-USFX

Primary Image
  • Product Image Thumbnail 1 of 2
  • Product Image Thumbnail 2 of 2
Free Shipping with $49 Minimum Order

Our Price:

$2,150.00

Availability: Typically Ships in 3-10 Business Days
iAvailability Description Popup


    DCI2X300N-U-USFX - Overview

    Audio Innovation Beyond Compare

    The Crown DCI2X300N-U-USFX is a DriveCore™ Install Network Series amplifier. The DriveCore™ Install series amplifiers are a complete line of high performance installation amplifiers based on the proprietary DriveCore technology. These amplifiers are equipped with on-board DSP allowing gain, EQ, delay and other parameters to be controlled from a remote location. Inputs can be a combination of analogue audio (balanced audio) and digital audio via HARMAN's BLU link high-bandwidth, low-latency audio bus.

    INNOVATION
    As the undisputed leader in sound amplification, Crown builds on its legacy of innovation and insight with the industry's first 100V direct drive amp: the DriveCore™ Install Amplifier Series (DCi). The ideal choice for everything from meeting rooms to massive stadiums, the highly efficient DCi Series saves you time because it configures quickly and is simple to use. Plus, its lighter, space-saving design makes it easy to install wherever you want. Designed, engineered and manufactured to the industry's highest quality standards for analog or network installations, the DCi Series provides system integrators with effortless, unmatched performance time after time.

    A SOUND DIFFERENCE YOU CAN SEE
    Designed for minimum size and maximum power, DriveCore offers greater accuracy, reduced weight, and best-in-class signal-to-noise performance. The front-end drive circuits leverage the inherent audio.

    GREENEDGE™ TECHNOLOGY
    The DCi Series is a direct result of this HARMAN initiative designed to increase performance and acoustic qualities while dramatically reducing energy consumption. With the DriveCore chip replacing over 500 parts, it requires far fewer materials while easily delivering more than 90% efficiency. The Powersave feature provides additional energy savings with an Auto-Standby mode that powers down the amp to consume less than 1W. Plus, using recycled cardboard boxes to ship DCi units further reduces our carbon footprint.

    • Features:

      • BLU-Link - BLU-Link capabilities make DriveCore Install Network amplifiers the end-all system solution for everyone
      • SAFETY - EN 54-16 Compliant for Life Safety Applications
      • TRUE RACK DENSITY - Power points of 300W or 600W in 2-/4-/8-channel configurations - all in a 2 Rack Unit form factor. More channels in one box allow smaller infrastructure rooms that can reduce operational costs while giving you the utmost in installation flexibility.
      • DIRECT DRIVE CONSTANT VOLTAGE - Save money by using smaller gauge wiring to drive the speakers using either 70V rms or 100Vrms. With no need for a step-up transformer at the output, the DCi produces higher audio quality much more efficiently.
      • CHANNEL INDEPENDENT HI-Z/LOW-Z SELECTION - Drive either one or two speakers in low-Z mode, or literally hundreds of speakers in high-Z mode (70Vrms or 100Vrms). This means better design flexibility since DCi powers all loads on a channel-by-channel basis.
      • BRIDGEABLE CHANNEL PAIRS - Unlike amps from other manufacturers, the DCi Series channels are bridgeable - even in 100Vrms mode - which means even more adaptability for higher power applications such as subwoofers.
      • REMOTE ON/OFF INTERFACE - Save power by integrating the amplifier into a control system so you can easily turn it on and off.
      • EFFICIENT COOLING DESIGN - Highly efficient internal cooling fans provide airflow to the most heat-generating parts. Incorporating the fans into the amplifier brick design maximizes cooling while minimizing wasted energy and noise.
      • ADVANCED POWER FACTOR CORRECTION (PFC) UNIVERSAL POWER SUPPLY - The most advanced power supply in an installation amplifier delivers power more efficiently in almost any condition than anyone else, resulting in less power dissipated and less heat in your racks.

    • Specifications:

      • PERFORMANCE SPECIFICATIONS
      • Frequency Response: (1W into 8O, 20Hz - 20kHz): ±0.25dB
      • Signal to Noise Ratio (A-weighted): >108dB
      • THD: <0.35%
      • Maximum Input Level before Compression: +20dBu
      • Maximum Input Level before Clip: +26dBu
      • Voltage Gain: 34dB

      • PHYSICAL SPECIFICATIONS
      • Input connectors: Balanced 3-pin block connectors, one per channel
      • Output connectors: 2 Pin terminal strip. Accepts up to 10AWG terminal forks and bare wire
      • AUX connector: 3-pin block connector
      • Attenuation Control: 21 detent potentiometer for levels from 8 to 0dB
      • Dimensions: 3.5" x 19" x 14.25" (8.75 cm x 47.5 cm x 35.63 cm)
      • Weight: 18.8 lbs (8.53 kgs)
      • Cooling: Continuously variable speed fan, front-to-back airflow
      • NETWORK DCi AMPLIFIERS INCLUDE THE PHYSICAL SPECIFICATIONS LISTED ABOVE, PLUS:
      • BLU link Input: (2) RJ-45 Connectors
      • Network Monitoring and Control: (1) RJ-45 Connector
      • General Purpose Input/Output Control: (1) RJ-11 for 2 Ins and 2 Outs

      • ELECTRICAL SPECIFICATIONS
      • Required AC Mains (±10%): 100VAC - 240VAC 50/60Hz
      • Power Draw in Sleep: Less than 1W
      • Power Connector: IEC 15A, 20A, & 30A

    • Item Includes:

      • 1x DCI2X300N-U-USFX Power Amp
      • 1x AC Power Cord - US

    • Warranty:

      • Three-year, no-fault, fully transferable warranty

    • GTIN:

      0691991009327
