The Speaker enclosure will require a 6 5/16 inch (160mm) mounting hole in the ceiling material. Tile bridges are supplied to support the weight in 2' x 2' or 2' x 4' acoustic tile ceilings. A connection point for support wires is also provided on the rear to meet installation requirements in earthquake prone areas. Complete installation instructions and cutting template are included with the speakers.
The connection screw terminals are located under a metal cover plate at the rear of the unit. The speaker should be used with 8 Ohm bypass setting for FS-200 installations. A switch is located under the speaker grill to change settings, use the 8 Ohm bypass position.
