OCC CX008HBWA9KR SMPTE Riser WBT Indoor/Outdoor Cable - 2 Fiber - 4x 20/2x 24 AWG w/ TC - UV Resistant Blk 500 Ft

ITEM #: CX008HBWA9KR-500 MFG #: CX008HBWA9KR-500

Primary Image
  • Product Image Thumbnail 1 of 2
  • Product Image Thumbnail 2 of 2
Optical Cable Corp
Free Shipping with $49 Minimum Order

List Price:

$1,640.00

Our Price:

$1,249.00

Add to Wish ListLeasing Options
Availability: Usually Ships in 5-14 Days.
Please Email, Chat or Call (800) 522-2025 for Detailed Delivery Info
iAvailability Description Popup
Notify when in stock
  • Special Order Item: non-cancelable, non-returnable, non-refundable.
Report Lower PriceLarge Quantity Quote

CX008HBWA9KR-500 - Overview

SMPTE-Riser Rated, with Waterblocking Tape - Broadcast Cables

Offering the durability you expect from OCC, these new SMPTE cables allow you to source all your connection needs from one place. The TACTICAL, LSZH, FLEX, and Riser all utilize the OCC Ultra-Fox Plus deployable buffer system with the combination of a triple thickness 500æm diameter acrylate coating together with a hard elastomer 900æm tight buffer for maximum fiber protection. Permanent Installations Where UL Riser is Required Connects Cameras to Fixed Wall Box Connections.

  • Specifications:

    • Fiber Code/Count: SLA/2
    • Industry Standard Designation:
      - Bend Tolerant
      - Singlemode
      - ITU-T G.657.A1, ITU-T G.652.D (Yellow and Blue)
    • Core/Cladding Diameter: 9/125µm
    • Wavelength: 1310/1550nm
    • Maximum Cable Attenuation: 0.5/0.5dB/km
    • Primary Coating Diameter: 245µm
    • Secondary Buffer Diameter: 900µm
    • Zero Dispersion Slope: 0.092ps/nm²-km
    • Proof Test Level: 100kpsi
    • Jacket Color: UV Resistant Black
    • Jacket Material: Riser Rated PVC
    • Buffer Material: Indoor/Outdoor PVC
    • Subunit OD: 0.9mm
    • Cable Weight: 80lbs/1000ft (119kg/km)
    • Cable Diameter: 0.36" (9.14mm)
    • Strength Member: 16 AWG Galvanized Steel PVC Insulated - Purple
    • Tape: Water-Blocking Tape, Overall, 100% Coverage
    • Operating Temperature: -4°F - 167°F (-20°C - 75°C)
    • Installation Temperature: 32°F - 167°F (0°C - 75°C)
    • Standards: UL Subject 444, Type CMR-OF/FT4
