Gefen EXT-DVI-142DLN One Dual Link DVI Source Splitter to two Dual Link DVI Outs

ITEM #: GEF-EXTDVI142DLN MFG #: EXT-DVI-142DLN

Primary Image
  • Product Image Thumbnail 1 of 5
  • Product Image Thumbnail 2 of 5
  • Product Image Thumbnail 3 of 5
  • Product Image Thumbnail 4 of 5
  • Product Image Thumbnail 5 of 5
Free Shipping with $49 Minimum Order

List Price:

$494.55

Our Price:

$341.00

Availability: Ships Factory Direct, Typically in 3-10 Business Days
iAvailability Description Popup


    EXT-DVI-142DLN - Overview

    The new and improved dual link 1:2 DVI DL Distribution Amplifier splits video using a dual link DVI source such as a computer to two DVI dual link outputs such as monitors, without losing picture quality or the high resolution. Multiple1:2 DVI DL units can be cascaded from one to the next to create a flexible Dual Link DVI distribution system that can connect to multiple displays.

    Connect a Dual Link DVI source to the 1:2 DVI DL unit using the included dual link DVI cable. Connect up to two Dual Link DVI devices to the DVI outputs. Connect the included 5V DC power supply to the unit using any available electrical AC out.

    • Features:

      • Split a Dual Link DVI signal to two DVI Dual Link outputs
      • Allows simultaneous display of source on two screens
      • Supports Single Link DVI resolutions up to 1920 x 1200, and dual-link up to 3840 x 2400
      • Auto EQ compensates for any imperfections in the image
      • Power On indicator
      • DVI Link indicators
      • Supports DDWG standard for DVI-compliant monitors
      • HDCP pass-through on output #1

    • Specifications:

      • Maximum Pixel Clock: 2 x 165 MHz
      • Video Input Connector: (1) DVI-D, 29-pin, female
      • Video Output Connectors: (2) DVI-D, 29-pin, female
      • Power On indicator: (1) LED, blue
      • Link indicators: (2) LED, green
      • Power Consumption: 20 W (max.)
      • Power Supply: 5V DC
      • Operating Temperature: 0 to +40°C
      • Dimensions (W x H x D): 4" x 1.25" x 3.25" (102mm x 32mm x 83mm)
      • Shipping Weight: 2 lbs (0.9 kg)

    • Item Includes:

      • (1) 1:2 Dual Link DVI Distribution Amplifier (EXT-DVI-142DLN)
      • (1) 6 ft. Dual Link DVI Copper Cable (M - M) (CAB-DVIC-DL-06MM)
      • (1) 5V DC Power Supply (EXT-PS526AIPN)
      • (1) Quick-Start Guide (QSG-DVI-142DLN)

    • GTIN:

      0845344085678
