Kiloview D300 4k UHD NDI HX HDMI - SDI Video Decoder

ITEM #: KV-D300 MFG #: D300

  • Product Image Thumbnail 1 of 2
  • Product Image Thumbnail 2 of 2

This item is no longer available.
Ask a Markertek Expert if you need assistance finding an appropriate substitute.

800-522-2025Email

Items similar to the KV-D300

D300 - Overview

The Kiloview D300 4K UHD NDI HX Video decoder is a professional hardware decoding device that can decode multiple video streams without relying on a computer It outputs SDI signal and HDMI signal video, supports 4K UHD resolution, and supports multi-channels video stream split screen to the display wall and dynamic switching.

Applications:
When you need to decode and split the multi-channel4K UHD network video stream, even if you need to switch the multi-channel network stream to the wall, you only need to connect the D300 4K UHD decoder to the network and the large screen interface. Various web videos can be presented in real time on a large screen according to your needs.

  • Features:

    • NDI HX, H.265, H.264 Decoding
    • Multi-stream switching
    • SDK provided
    • 4K UHD resolution
    • Image scaling/ frame rate conversion
    • 16 channels video split to the screen
    • Ultra low latency decoding
    • 7*24h working mode
    • SRT supported

  • Specifications:

    • Input: 2x 100M/1000M RJ-45 adaptive Ethernet port
    • Video Output:
      1x SD/HD/3G-SDI, support up to 1080p 60Hz
      1x HDMI 2.0, support up to [email protected]
    • Output Format:
      SDI: up to 1080p60Hz
      1080I60/59.94/50 720P60/59.94/50 570I/50
      480I/60
    • HDMI: up to 4k
      4k [email protected]/30
      1080p60/50
      1080p24/25/30
      1080p60/50
      720p60/50
      Compatible with VESA standard format
    • Audio Output: SDI/HDMI embedded or analog line-out output
    • Media Protocol: RTMP/SRT/HLS/TS over UDP/RTP/RTSP/ONVIF
    • SDI Transmission Distance: Belden 1694A cable standard: SD SDI≥ 180m; 3d SDI ≥ 100m
    • Video Decoding: NDI HX/H.265/H.264
    • Audio Decoding: AAC/G.711
    • Decoding Delay: <200ms
    • Decoding Ability:
      4K 30Hz: up to 4 channels simultaneously
      1080P 50Hz/60Hz: up to 8 channels simultaneously
      1080P 30Hz, 1080I 50/60Hz or 720P and below: up to 16 channels simultaneously
    • Split Screen Display: Support 1/2/4/6/8/9/16 self-defined screen spitting
    • Management: Web
    • Power Supply: 12V 1A
    • Consumption: 5w
    • Operating Temperature: -4° to 140°F (-20° to 60°C)
    • Dimensions: 5.4 x 4.1 x 0.9" (13.8 x 10.5 x 2.5cm)
    • Weight: 0.83Lbs (380g)

  • GTIN:

    0653559999235
