Laird Bates Style Stage Pin Power Extension Cable Male to Female - 10 Foot

ITEM #: LDC-BSPM-F-010 MFG #: LDC-BSPM-F-010

Primary Image
Free Shipping with $49 Minimum Order

List Price:

$56.49

Our Price:

$51.49

Availability: Usually Ships in 5-14 Days.
Please Email, Chat or Call (800) 522-2025 for Detailed Delivery Info
iAvailability Description Popup


LDC-BSPM-F-010 - Overview

The male to female Laird Stage Pin Extension cable delivers an easy way to locate and relocate studio set lighting or theatrical stage lighting – especially for those grips who don’t have time to make their own. These stage pin lighting cables are built with SJOOW heavy duty 12/3 wire and terminated with 20 Amp 125V Bates style stage pin connectors. Laird Stage Pin Cables provide a safe and easy way to make your lighting connections!

  • Features:

    • Laird's heavy-duty flexible SJOOW PWR-12/3-TP power cable
    • Rugged 20-amp connectors
    • UL-recognized components

  • Specifications:

      Laird PWR-12/3-TP Cable:
    • Cable Type: SJOOW
    • Number of Conductors x AWG: 3x12
    • Conductor Insulation: Rubber (EPR)
    • Outer Jacket Material: Rubber (CPE)
    • Current Carrying Capacity: 25 Amps
    • Outer Diameter: 0.425in - 0.476in
    • Nom. Voltage: AC U 300V
    • Temperature:
      • Flexing: -4°F to 194°F (-20°C to +90°C)
      • Static: -40°F to 194°F (-40°C to +90°C)
    • Min Bend Radius:
      • Flexing: 4.76in
      • Static: 2.85in
    • Weight: 0.14lbs/ft

      Bates Connectors:
    • Max. Amperage: 20 Amps
    • Max. Voltage: 250 Volts
    • Housing Material: Thermoplastic
    • Contact Material: Brass

  • Warranty:

    • 1 Year
