Lilliput Electronics TK2380/T 23.8-Inch 1000 Nits Touch Screen Monitor

TK2380/T - Overview

Industrial-Grade Touch Monitor

• Features:

  • 10-point capacitive touch screen, support gloves touch
  • 1000cd/m² high brightness
  • Support multiple video input interfaces: HDMI, VGA, AV
  • Support audio input
  • Support HDMI 4K 30Hz
  • Support Windows XP/7/8/8.1/10, Android, Linux and MAC OS
  • Full lamination screen with AG (Gloss70), AF and UV resistance
  • Hardness 7H, impact resistance IK07


• Specifications:

  Display
  • Panel: 23.8" LCD
  • Physical Resolution: 1920x1080
  • Aspect Ratio: 16:9
  • Brightness: 1000 nits
  • Contrast: 1000:1
  • Viewing Angle: 160° (H)/160° (V)

    Inputs
  • HDMI: 1
  • VGA: 1
  • Video & Audio: 1

    Supported Formats
  • HDMI: 2160p 24/25/30, 1080p 24/25/30/50/60, 1080i 50/60, 720p 50/60
  • VGA: 1080p 24/25/30/50/60, 1080pSF 24/25/30, 1080i 50/60, 720p 50/60
  • Video & Audio: 480i 60Hz, 576i 50Hz

    Audio In/Out
  • Speaker: 2
  • HDMI: 2ch
  • Ear Jack: 3.5mm - 2ch 48kHz 24-bit

    Power
  • Input Voltage: DC 12V - 24V
  • Power Consumption: ≤13W (12V)

    Environment
  • IP Rating: IP65 Front Panel
  • Operating Temperature: -4°F - 140°F (-20°C - 60°C)
  • Storage Temperature: -22°F - 158°F (-30°C - 70°C)

    Physical
  • Dimension(LxWxD): 23" x 21" x 4" (584.2mm x 533.4mm x 101.6mm)
  • VESA Mount: 2.95" (75mm)
  • Weight: 4lbs (1.8kg)
  • Shipping Weight: 22lbs (10kg)


• Item Includes:

  • 1x 12V/2A DC Adapter
  • 1x HDMI A/A cable
  • 1x VGA Cable
  • 1x Audio/Video Cable
  • 6x Screw Kits
  • 4x Cable Clamp
  • 1x User Manual


• Warranty:

  • 1 Year Limited Warranty


• GTIN:

  6950821605158
