Middle Atlantic SNE24D-2442-P1 Digital Enclosure Rack

SNE24D-2442-P1 - Overview

• Features:

  • Lever Lock™ compatible (accepts all 21" vertical accessories)
  • UTL/ETL listed and seismic certified
  • Configured for passive front-to-back cooling
  • Includes 70% open front door and 70% open area split rear door
  • Includes solid top with brush cable pass-through
  • Includes pair of split flush mount locking side panels
  • Includes 2 pair of adjustable cage-nut rackrail
  • Includes 100 6mm cage nuts and rack screws


• Specifications:

  • Gangable: Yes
  • Finish: Black Powder Coat
  • UL Standards Tested: UL2416
  • Component Type: Passive
  • RoHS: Yes
  • Greenguard: Yes
  • ETL Listed: Yes
  • UL Listing No: E313734
  • UL Standard: Yes
  • Usable Depth: 38.48
  • Usable Height: 42
  • Panel Width: 19
  • Capacity Weight (US): 12000
  • Depth (US): 43.15
  • Height (US): 48.02
  • Width (US): 24
  • Rack Units: 24
  • Rackrail Type: Cage Nut
  • Static Load Capacity: 12000
  • UL Load Capacity: 3000
  • Material: Steel
  • Mounting: Horizontal
  • Seismic Rating: Yes


• GTIN:

  0656747207761
