MediaEdge ME-BXC-CM100 QDCAM High-Speed Box Camera for Sports

Name: MediaEdge ME-BXC-CM100 QDCAM High-Speed Box Camera for Sports
Brand: MEDIAEDGE
SKU: ME-BXC-CM100
Price: 5939.01 USD
Availability: PreSale

ITEM #: ME-BXC-CM100 MFG #: ME-BXC-CM100

MEDIAEDGE

List Price:

$5,999.00

Our Price:

$5,939.01

Add to Wish List Leasing Options

Availability: Typically Ships in 3-10 Business Days

Report Lower Price Large Quantity Quote

Overview

Recommended Accessories

Reviews

Attachments

Required Accessories

Recommended Accessories

ME-BXC-CM100 - Overview

MEDIAEDGE ME-BXC-CM100 is a QDCAM high-speed 4xFHD and UHD box camera, supporting both FHD 240/200fps and UHD 60/50 fps video formats. Highly recommended for sports coverage, QDCACM allows for UHD high resolution production or high speed shooting with a single camera.

QDCAM is equipped with a global shutter CMOS image sensor to avoid the rolling shutter distortion of quick moving objects.

High-Speed shooting: 1920x1080/239.8p, 200p: Continuous 4X high-speed video for smooth slow-motion replay. Quad link of SDI output.

Please Note: Lens and AC adapter are sold separately.

Features:
- Continuous 4X high-speed video
- Quad-link SDI
- 4K cinema/UHD video
- Optical transmission option using SMTPE opt-camera cable
- Micro four thirds lens mount
- Remote control of iris and focus available
- Global shutter CMOS sensor

  Applications
- Slow-Motion Replay
- Multi-Angle View
- Image Analysis for Sports Judgement System
- Wide Angle & Closeup Shot for Sports Broadcast
- Video Capture Tool for Sports Coaching
Specifications:
- Image Pickup Device: 1/1.1" 8.8 million-pixel CMOS image sensor with Global shutter
- Method: Single image sensor with Bayer color configuration
- Lens Mount: Micro four thirds system
- Output Video Format: 4096x2160/24p, 23.98p (quad 1.5G-SDI) / 3840x2160/60p, 59.94p, 50p (quad 3G-SDI) / 3840x2160/24p, 23.98p (quad 1.5G-SDI) / 1920x1080/240p, 239.8p, 200p (quad 3G-SDI) 1920x1080/60p, 59.94p, 50p (3G-SDI) / 1920x1080/24p, 23.98p / (1.5G-SDI) / 1920x1080/59.94i, 50i (1.5G-SDI)
- Genlock Reference: Tri-level Sync or Black Burst
- Operating Temperature: 23° to 113°F (-5° to 45°C)
- Weight: 1.52 lbs (690g)
- Dimensions: 2.95 x 2.95 x 5.00" (75 x 75 x 127mm) (excluding protrusions)
- Power Consumption: 10W (excluding lens/controller power)
- Source Voltage: DC 13.8V (DC 11.8V to 16.8V)
Item Includes:
- 1x MEDIAEDGE High Speed Box Camera - (Lens and AC adapter are sold separately)
GTIN:
4562393843009
