E-IMD-LCV2 - Overview

The E-IMD-LCV2 is a low-cost infrared motion sensor with advanced technology in signal processing and provided with high detection ability with protection against false alarms. When used with the ENVIROMUX Series Environment Monitoring Systems it will provide indication and alerts when it detects human motion/intruders that pass through the detection area.

  • Features:

    • Registers movement in area covered: 39x39 ft (12x12 m), 110° wide.
    • Condition display via LED.
    • Intelligent logic control prevents false alarms.
    • Wall mount or hang in a corner.
    • Good RFI protection.
    • Screw terminal
    • To connect to the digital inputs use a 22 AWG 2-wire cable. Connect the other end to the sensor screw terminal.
    • Maximum cable length: 1,000 ft (305 m).
    • Includes mounting bracket for installing the sensor to a ceiling or wall.
    • Powered by E-16D/5D/2D


  • Item Includes:

    • NTI E-IMD-LCV2 Infrared Motion Detector
    • 110-240VAC, 50 or 60Hz-12VDC/1A AC Adapter (E-IMD-LCV2P model only)
    • Country-specific Line Cord (E-IMD-LCV2P model only)
    • Mounting hardware
