NTI E-2D Enviromux Small Enterprise Environment Monitoring System

E-2D - Overview

• Features:

  • Configure Smart Alerts for different event combinations
  • 2 external configurable sensors, 5 digital inputs, 1 output relay
  • User-programmable IP camera snapshots
  • Optional back-up battery, Power over Ethernet (POE), or 24VDC/48VDC power
  • Linux inside
  • Cascade up to 5 units via Ethernet connection (1 master, 4 slaves)


• Specifications:

  • RJ45 Sensor Ports: 2x female RJ45 jacks for connecting NTI temperature, humidity, liquid detection, smoke detection, glass break, vibration, motion sensors, and more. Two levels of user-defined alerts - non-critical and critical. Provides +12 VDC, 100 mA for each port.
  • Dry Contact Closures:
    - Five screw terminal pairs for connecting dry contact devices and the liquid detection sensor.
    - Potential-free.
    - Output voltage: +5 V DC
    - Current limited to 10 mA
    - Maximum resistance to close contact: 300K Ohm
  • Output Relay:
    - One screw terminal pair.
    - Potential-free relay switch contacts.
    - Normally open / normally closed connection points.
    - Maximum switching load: 1A at 125VAC or 30VDC.
  • USB Ports:
    - 2x female USB Type A connectors for connecting USB modem or for downloading log data to USB flash drive.
    - 1x female USB Type B connector for connecting a PC for serial terminal access.
  • Ethernet Port
    - 1x female RJ45 connector.
    - 10/100 Base-T Ethernet interface. Supports full- and half-duplex.
  • Power Output: AUX Power (One screw terminal pair. Provides +12 VDC, 500 mA.)
  • Optional Back-Up Battery:
    - Rechargeable sealed lithium battery.
    - Provides back-up for two hours.
  • Protocols:
    - HTTP/HTTPS, SNMP V1/V2c/V3, SMTP, TCP/IP, Syslog, SNTP, DHCP, SSHv2, SSLv3, TLS v1.2, LDAPv3, XOAUTH2, AES 256-bit, 3DES, Blowfish, RSA, EDH-RSA, Arcfour, IPV6, WAP 2.0, RADIUS (Support for XOAUTH2 provides higher security authentication for email accounts (e.g. Gmail).)
    - Compatible with any SNMP management software. (The unit can be polled via SNMP.)
    - Operates and configures via HTTP/HTTPS web page, Telnet, SSH, or USB serial interface. (Supports Internet Explorer 6.0 and higher, Firefox 1.5 and higher, Netscape 9, Google Chrome, Safari 1.3 and higher for MAC, and Safari 3.0 and higher for PC.)
    - Multiplatform support: Windows 7/8/10/11, Windows Server 2008/2012/2016/2019/2022, Solaris, Linux, FreeBSD, and MAC OS 10/11/12.
    - An IP address can be assigned to the E-2D automatically by a DHCP server.
    - Generates SNMP traps, email alerts, syslog messages, and SMS messages (via USB 3G modem). (Alerts are posted in event log, which is accessible through Web user interface. Email alerts can be sent to 17 addresses.)
    - Supports HTTP REST API to poll sensor data with response in JSON format.
  • Dimensions (WxDxH): 5.82" x 3" x 1.75" (148mm x 76mm x 44mm)
  • Weight: 1.0lbs (0.45kg)
  • Power: Dual DC power (If the first power source fails, the unit will automatically, without interruption, switch over to the second power source before switching to the optional battery backup.)
  • Input: 100 to 240 VAC at 50 or 60 Hz via AC adapter. (Includes one 9VDC, 3A country-specific AC adapter. The second AC adapter is sold separately.)
  • Voltage output: 9-12VDC
  • Power consumption: 10W
  • Operating temperature: 32°F to 140°F (0°C to 60°C)
  • Storage temperature: -22°F to 140°F (-30°C to 60°C)
  • Operating/Storage Relative Humidity: 5% to 90% non-condensing RH


• Item Includes:

  • 1x E-2D


• Warranty:

  • 2 Year Limited Warranty
