OCC RTC2U-6APB RTC Series - Rack Mount Fiber Enclosures

ITEM #: OCC-RTC2U-6APB MFG #: RTC2U-6APB

Primary Image
Free Shipping with $49 Minimum Order

List Price:

$204.11

Our Price:

$185.55

Availability: Typically Ships in 3-10 Business Days
iAvailability Description Popup


    RTC2U-6APB - Overview

    OCC is committed to providing the best fiber cabling system in the industry. Their newly redesigned fiber termination enclosures introduce new features to a well-established product line, making them easier to work with and more aesthetically pleasing while maintaining the ruggedness expected from Optical Cable Corporation. The RTC2U-6APB fiber optic enclosures allow for easier terminations, greater capacity and uncomplicated cable management. Fabricated from 16 gauge steel to withstand years of adds, moves and changes, the new RTC and RTS enclosures incorporate features designed to reduce installation time and cost.

    • Features:

      • Designed with features that benefit both the end user and the installer, OCC’s new enclosures offer the following:
      • Available in both fixed (RTC) and sliding (RTS) versions1RU, 2RU, and 4RU configurations available to accommodate project size
      • RTC and RTS enclosures are built on the same chassis for rack uniformity
      • RTC and RTS enclosures accept OCC standard 600 series adapter plates
      • RTC-HD and RTS-HD enclosures accept new HD adapter plates for high-density applications
      • External cable management is enhanced with new modular strain relief brackets that reduces fiber stress and provides support for proper cable bends and efficient cable management
      • Fiber hoops in the rear of the cabinet are stackable and allow for greater segregation of incoming fiber cables
      • Fiber retention teeth on the cable hoops retain the fiber within the hoop simplifying cable management during installation
      • New slam latches on the front and rear of the enclosures make access easier
      • Both the RTC and RTS series enclosures provide a transparent cover for visual inspection of ports and a defined labeling field for TIA 606A compliance
      • Hardware included for 19"
      • or 23"
      • rack mounting
      • Numerous internal locations to secure slack cable

    • Specifications:

      • Fiber Enclosure
      • Rack Mount
      • 2RU
      • Sliding
      • 6 Adapter Plates


    RTC2U-6APB - Required Accessories
