    S3D7P6G960 - Overview

    This OWC S3D7P6G960 internal 2.5" SATA SSD delivers the highest transfer speed, endurance, and performance available today.

    With sustained reads up to 559MB/s and writes up to 527MB/s, up to 100x greater data protection than enterprise class Hard Disk Drives, and RAISE technology for RAID like data protection and reliability, the OWC Mercury Extreme SSD line delivers unbeatable performance. It's also backed by a 5 Year OWC SSD Limited Warranty.

    High Performance Internal Storage
    Replace your conventional hard drive with a reliable solid state drive. Unlike traditional hard disk drives, OWC solid state drives have no moving parts, resulting in a quiet, cool, and highly rugged storage solution that also offers faster system responsiveness.

    High Reliability & Protection
    OWC SSDs allocate some of the drive capacity for RAISE, to provide real time data redundancy, ECC Error Correction, and reserve cell space.

    Includes 7 mm to 9.5 mm Adapter / Spacer
    Attach this adapter to the top of any 7mm, 2.5-inch drive for installations that require a 9.5mm drive height for proper use, whether you need a 9.5mm drive height for a dock, camera, server, device, PC, or external drive. This adapter is not needed for 2.5-inch drive installations that use the standard side or bottom mounting positions to secure the drive in place, and is not needed for any installation of a 7mm drive in Apple Macintosh computers.

    Example: A 240GB OWC Mercury Extreme Pro SSD is actually a 256GB drive with 7% of the drive's capacity allocated for data management. This management maintains the drive's high-performance and high reliability levels. Unlike many SSDs on the market today, the Mercury Pro family uses advanced DuraWrite™ wear-leveling and block management technologies to keep Read/Write performance at peak, while others see performance fall.

    • Features:

      • Global wear leveling algorithms automatically distribute data evenly and manage program/erase count, maximizing SSD lifespan
      • StaticDataRefresh manages free space, gradually refreshing data across the SSD over time, preventing data corruption
      • Hardware BCH ECC corrects errors up to 66-bit/1KB for superior data retention and drive life
      • Advanced security protocols support 128/256-bit-AES disk encryption

    • Specifications:

      • Physical
      • Dimensions (HxWxL): 0.276 x 2.758 x 3.941" (7 x 70.06 x 100.12)
      • OWC 7mm - 9.5mm Adapter included (buy additional)
      • Weight: 0.170Lbs ±2.71oz (77g ±2g)

        Reliability
      • Data Reliability
      • Built-in BCH ECC: Up to 66 bits correctable per 1024 bytes
      • Security
      • Chip Based Data Encryption: 256-bit AES-compliant
      • TRIM SupportOS Dependent
      • Nonrecoverable Read Errors
      • Less than 1 sector per 1016 bits read

        Performance
      • Sequential Reads (6Gb/s, Compressible Data)
      • 535 MB/sSequential Writes (6GB/s, Compressible Data)
      • 435 MB/sSequential Reads (6GB/s, Incompressible Data)
      • 520 MB/sSequential Writes (6Gb/s, Incompressible Data)
      • 431 MB/s

        Power
      • ActiveRead: 3000mW (3.0W) Maximum draw
      • Write: 4500mW (4.5W) Maximum draw
      • Idle Less than 1000mW (1.0W)

        Environmental (Operating)
      • Operating Temperature: 32° to 158°F (0° to 70°C)
      • Storage Temperature: -40° to 185°F (-40° to 85°C)

        Acoustics
      • Idle (Typical): 0.0 bels
      • Seek (Typical): 0.0 bels

    • Item Includes:

      • 1TB Mercury Extreme Pro 6G SSD
      • 7 mm - 9.5 mm Adapter

    • Warranty:

      • 5 Year OWC Limited Warranty

    • GTIN:

      0812437029390
