The P2P 12-Fiber LC/UPC Rolled E-Ribbon Pigtail with Stainless Steel Armor is engineered for rapid, high-density terminations in data centers, FTTH networks, and enterprise installations where space efficiency and long-term reliability are critical.
This product features a compact, jacketed 250µm G657.A2 flat ribbon fiber enclosed in oval tubing with internal rolled (E-ribbon) construction, providing a pre-aligned, splicing-ready configuration that dramatically reduces fusion splicing time.
It's protected by a durable outer sheath that includes a passivated stainless steel tube, ensuring resistance to crushing, moisture, and mechanical damage during and after installation.
Installers benefit from factory-controlled ribbon geometry and pre-routed 900µm color-coded breakout legs that eliminate the need for manual fan-out kits or fusion alignment adjustments. By using LC/UPC connectors with high precision alignment and color-coded booting, each breakout is clearly marked for seamless routing into patch panels or enclosures.
The design improves fiber management, enhances airflow in tight spaces, and significantly cuts installation time-while also maintaining robust optical performance and superior bend resistance thanks to G657.A2 glass. Customers gain a scalable, clean, and reliable interface ideal for modern optical networking infrastructure, while minimizing labor costs and ensuring consistent results in high-volume rollouts.
Key Advantages vs. Competitors:
- Stainless steel armored cable outperforms flexible other jackets for crush/pest protection
- Compact OD reduces bend radius challenges in riser or conduit installs
- Ships via UPS unlike other heavier alternatives which require freight
- Longer warranties and superior deployment flexibility across segments
