Plura PRM-317-3G 7RU 17 Inch Reference Broadcast Monitor with UHD 10-bit Panel (3840x2160)

ITEM #: PLUR-PRM-317-3G MFG #: PRM-317-3G

Primary Image
  • Product Image Thumbnail 1 of 3
  • Product Image Thumbnail 2 of 3
  • Product Image Thumbnail 3 of 3
Free Shipping with $49 Minimum Order

List Price:

$4,988.00

Our Price:

$4,489.20

Availability: Typically Ships in 3-10 Business Days
iAvailability Description Popup


    PRM-317-3G - Overview

    Plura PRM-317-3G is a 17-inch Reference Broadcast Monitor equipped with UHD 10 bit panel (3840x2160). supports up to 3G 1080P resolutions, 3D LUT, with waveform and vector scope.

    The monitor is field upgradable to PBM-217-4K with option "PRM-217-3GFW4K" and/or SFP-217-25G with option "PRM-217-3GFW25G".

    It was designed in alignment with increased industry demand for affordable, reliable and future proof reference monitor.

    Plura PRM-317-3G, PBM-217-4K and SFP-217-25G bring the exceptional built-in features Plura monitors are known for, maintaining quality and performance to give production facilities an edge in FHD, UHD(1,2) and 25G IP-2110(1) monitoring respectively.

    Plura PRM-317-3G, PBM-217-4K and SFP-217-25G focuses on delivering the highly detailed, accurate color representation and stunning picture consistency that high-end production applications require. Ember+ control capabilities are included, i.e. can be controlled by Lawo-VSM, BFE-Core or any other Ember+ compliant control system.

    • Features:

      • TRUE 10 bit panel color depth with 178° Viewing Angle Display
      • RGB 12 Bit Digital Signal Processing
      • 2 x 25 GbE SFP28 ports supporting ST 2110, ST 2022-7(1)
      • 1 x HDMI 2.0 HDCP 2.2 port
      • 2 x 12G(1,2), 6G(1,2), 3G, 1.5G ports
      • Quad 3G SQ(1,2) and 2SI(1,2) support
      • 1 x SFP-SDI Slot supporting Multiple I/O Standards
      • Supports up to 4096 x 2160 resolutions
      • HDR (High Dynamic Range) capabilities
      • PQ (SMPTE ST 2084) & HLG (Hybrid Log Gamma)
      • Gamma Selectable (0.8 - 3.0)
      • 3D LUT (ITU-R BT 2020, Native, BT.709, SMPTE-C, EBU, NTSC, D-Cinema)
      • Color Temperature - User, VAR, Adjustable (9300K TO 3200K)
      • (ICAC) - Plura Intelligent Connection for Alignment & Calibration
      • ColourSpace PRO tool integration, license is required
      • S-Log LUT curves integration included
      • NMOS, JT-NM Interoperability(1)
      • Ember+ Compliant, Ethernet & RS232 Remote Control
      • TSL 4.0, 5.0 and Internal Monitor Display (IMD) support
      • Cutting edge De-interlacing and Scaling Technology
      • Display Advanced Waveform & Vector Scope with line select
      • Programmable 6 User Front Pushbutton Controls & GPI
      • Various and User defined Markers Display Safe Area in HD and SD
      • Closed Caption (608/708) - North American Market
      • Teletext 801 & Subtitle OP-47- Australia & N.Z. Market
      • Fast Response Time for high motion video
      • Zeroscan / Pixel to Pixel Mode / Tally / DC Operation
      • False Color and Peaking Filter / Focus Assist
      • Video Range test with adjustable Y & C values
      • Display LTC & DVITC time code with line select
      • Embedded Audio Input, Digital Audio Decoding
      • Internal Pattern Generator and Wall Control System

    • Specifications:

      • Screen Size: 17"
      • Style: Desktop
      • Screen Resolution: 3840x2160
      • Backlight: LED
      • Color Depth: 10bit
      • Advanced Features: Closed Caption 708/608, Ember+, Optional IP2110 / 2022-7, Teletext 801 & OP-47, Battery Operation, HDR
      • Control: Ember+, Optional NMOS, Ethernet, IR, RS232, Wall Control System
      • ICAC: Yes
      • Video: Quad 3G (SQ/2SI), 12G, 3G, CCVS, DVI, HD-DL, HDMI, HDSDI, SDSDI, VGA, Y/C, YUV
      • Audio: Analog Audio, Embedded Digital Audio
      • Additional Features: Ember+, Closed Caption, Vectorscope, Waveform
      • Housing: VESA (100x100) & (75x75), Optional 19" Rack
      • RU: 7

    • Item Includes:

      • 1x Plura PRM-317-3G 7RU 17 Inch Reference Broadcast Monitor with UHD 10-bit Panel (3840x2160)
