Pure Resonance Audio DA2500 Dual-Impedance 500W Rack Mount Power Amplifier - 500W at 70V and 4 Ohms

ITEM #: PRA-DA2500 MFG #: PRA-DA2500

Primary Image
  • Product Image Thumbnail 1 of 2
  • Product Image Thumbnail 2 of 2
Free Shipping with $49 Minimum Order

List Price:

$1,319.99

Our Price:

$1,099.99

Availability: Usually Ships in 5-14 Days.
Please Email, Chat or Call (800) 522-2025 for Detailed Delivery Info
iAvailability Description Popup


PRA-DA2500 - Overview

The Pure Resonance Audio DA2500 is a dual-impedance 2-channel Class-D power amplifier with a built-in high-efficiency selectable impedance power supply. Each powerful 500W channel has an independent 70V/4Ω - 16Ω switch allowing them to simultaneously use a different impedance, delivering more flexibility in various commercial applications. This high-performance rack mount audio amplifier is a cost-effective solution housed in a standard 1U 19" lightweight chassis. The DA2500 features short-circuit, overload, and overheating protection with cooling fans to provide heat dissipation, maintaining safe operation in environments with long working hours.

  • Features:

    • Highly Efficient: High-performance switching power supply and Class-D type power amplifier provides 85% efficiency with low power loss and heat output.
    • Dual-Impedance: Unique dual-impedance operation with independent 4Ω - 16Ω and 70V output terminal switches enables each channel to use a different impedance simultaneously. The balanced inputs and outputs feature detachable Euroblock terminals.
    • Powerful: Two 500W channels (at 70V and 4Ω) with 70V and 4Ω, 8Ω, or 16Ω output switches.

  • Specifications:

    • Rated Power Output: 2x 500W at 70V, 500W at 4Ω, 250W at 8Ω
    • Speaker Outputs: 70V/4Ω - 16Ω
    • Input Sensitivity: ±385mV/20kΩ, balanced input
    • Frequency Response: 80Hz - 16kHz (+1dB, -3dB)
    • S/N Ratio: ≥95dB
    • THD: ≤0.1% (at 1kHz, 1/3 rated power)
    • Control: Power control and fault indication remote monitoring via Euroblock connection
    • Indicator Light: Signal, peak clipping, protection, and power supply
    • Protection: High temperature, overload, short-circuit
    • Cooling: Fan-forced cooling
    • Power Consumption: 1200W
    • Power Supply: ~110V - 120V 60Hz
    • Dimensions (HxWxD): 1.73" x 19.05" x 12.4" (44mm x 484mm x 315mm)
    • Weight: 10.8lbs (4.9kg)

  • Item Includes:

    • 1x DA2500 Dual-Impedance 500W Power Amplifier
    • 1x Power Cord

  • GTIN:

    0810093051168
