Skaarhoj MP-LYRA-V1B Mega Panel Lyra 1ME Live Switching Modular Panel Bundle - 24x Crosspoints

ITEM #: SKA-MP-LYRA-V1B MFG #: MP-LYRA-V1B

Primary Image
Free Shipping with $49 Minimum Order

List Price:

$17,287.00

Our Price:

$16,854.83

Availability: Usually Ships in 5-14 Days.
Please Email, Chat or Call (800) 522-2025 for Detailed Delivery Info
iAvailability Description Popup
  • Special Order Item: non-cancelable, non-returnable, non-refundable.


MP-LYRA-V1B - Overview

The SKAARHOJ Mega Panel is a modular concept within SKAARHOJ's hardware lineup. SKAARHOJ products are well known and recognized for their unparalleled software flexibility - supporting multiple brands and allowing customization down to the single-button, encoder, and fader level.

With Mega Panel, SKAARHOJ took it one step further. In addition to software flexibility, they now offer hardware flexibility. With modular components, you can build a control panel that perfectly fits your needs - simply join panels together to create a multi-ME or multi-crosspoint surface, expanded with auxiliary macro, audio, and PTZ sections.

Component selection is entirely up to you. However, to help you get started, they've designed five ready-to-go sets: Lyra, Draco, Orion, Cygnus, and Vela. These sets can be purchased as bundles but can also be customized by adding or removing modules.

Benefits:
- Works with major broadcast systems (Kairos, TriCaster, AMPP, Carbonite, ATEM, vMix and more).
- One control surface integrating multiple panels.
- Mounted in elegant 1ME wooden frame.
- Fully customizable software setup.

Recommended Accessories (sold separately):
- 1Gb Ethernet PoE switch with minumum 5 ports
- 4 x Ethernet Cable: Cat 6 S/FTP or better

  • Features:

    • 1ME live switching modular panel.
    • Consists of T-BLOCK-L-V1B-BK, 2 x MK48-V1B-BK, QUICK-SHOT-V1B-BK and MK-FRAME-1ME
    • 24 crosspoints, transition module and quick shot module.
    • All modules connect over 1Gb PoE Ethernet creating one surface.

  • Specifications:

      T-Block
    • Component Highlights: Exclusive SKAARHOJ Hall Effect T-Bar with LED ring Sculptured cap NKK broadcast buttons
    • Buttons: Elastomer Four-Way Button (x8); Sculptured Hard Cap Button (x15)
    • Analog Components: T-bar Large w/RGB (x1)
    • Programmable OLED Tiles: 64x48 pixels (x8); 256x26 pixels, gray (x3); 64x58 pixels, gray (x4); 64x32 pixels, gray (x8); 64x26 pixels, gray (x8); 84x32 pixels, gray (x2); 88x32 pixels, gray (x1); 128x32 pixels, gray (x2)
    • Other: OLED Display Tile (x28); LED-Bar, 15 steps (x1)
    • Networking: 1G Ethernet w/Power over Ethernet (PoE IEEE802.3af/t)
    • Power Supply: 12V DC Jack 5.5mm x 2.1mm x 10mm Center Positive PoE IEEE802.3af/t
    • Service Port: Micro USB for setting manual IP
    • Peripherals: USB-A 2.0 (500 mA) for Stream Deck, X-keys, additional networking adapters, frame grabbers etc.
    • Platform: Blue Pill (Reactor, Device Cores, skaarOS Linux)
    • Licenses: Full Reactor and Device Core licenses included

      Quick Shot
    • Buttons: Elastomer Four-Way Button (x28)
    • Programmable OLED Tiles: 64x48 pixels (x28)
    • Networking: 1G Ethernet w/Power over Ethernet (PoE IEEE802.3af/t)
    • Power Supply: 12V DC Jack 5.5mm x 2.1mm x 10mm Center Positive PoE IEEE802.3af/t
    • Service Port: Micro USB for setting manual IP
    • Peripherals: USB-A 2.0 (500 mA) for Stream Deck, X-keys, additional networking adapters, frame grabbers etc.
    • Platform: Blue Pill (Reactor, Device Cores, skaarOS Linux)
    • Licenses: Full Reactor and Device Core licenses included

      Master Key 48
    • Component Highlights: Sculptured cap NKK broadcast buttons
    • Buttons: Sculptured Hard Cap Button (x36); Elastomer Four-Way Button (x12)
    • Programmable OLED Tiles: 64x58 pixels, gray (x12); 64x32 pixels, gray (x12); 64x26 pixels, gray (x12); 64x48 pixels (x12); 256x26 pixels, gray (x3)
    • Other: LED-Bar, 3 steps, Large (x12); OLED Display Tile (x39)
    • Networking: 1G Ethernet w/Power over Ethernet (PoE IEEE802.3af/t)
    • Power Supply: 12V DC Jack 5.5mm x 2.1mm x 10mm Center Positive PoE IEEE802.3af/t
    • Service Port: Micro USB for setting manual IP
    • Peripherals: USB-A 2.0 (500 mA) for Stream Deck, X-keys, additional networking adapters, frame grabbers etc.
    • Platform: Blue Pill (Reactor, Device Cores, skaarOS Linux)
    • Licenses: Full Reactor and Device Core licenses included

  • Item Includes:

    • 1x T-BLOCK-L-V1B-BK
    • 2x MK48-V1B-BK
    • 1x QUICK-SHOT-V1B-BK
    • 1x MK-FRAME-1ME

  • GTIN:

    0571407400355
