Studiomaster DigiLive 08C 8 Channel Digital Console

ITEM #: SM-DIGILIVE-08C MFG #: DIGILIVE 08C

Primary Image
  • Product Image Thumbnail 1 of 3
  • Product Image Thumbnail 2 of 3
  • Product Image Thumbnail 3 of 3
Free Shipping with $49 Minimum Order

List Price:

$719.00

Our Price:

$565.00

Availability: Ships Factory Direct, Typically in 3-10 Business Days
iAvailability Description Popup


    DIGILIVE 08C - Overview

    The Studiomaster Digilive 8C is a Simple to use interface with 3 operation modes FULL BASIC LOCK (lock mode only allows fader/media operation). The Digilive 8C has 4 band parametric EQ HPF and intuitive operation SAVE EQ TO PRESETS (basic mode converts EQ to 4 band fixed). Analogue inspired bus/effect routing, double tap the faders to get fast to zero EASY TO VIEW BUS ROUTING (you can even choose pre or post fade). High quality compression and gate dynamics, save presets to your library for easy recall, basic mode gives simple one control (easy to understand graphical display). Media player with simultaneous recording, play multiple formats from MP3 to WAV, ONE TOUCH OPERATION TO PLAY (records L/R main mix in stereo WAV). 31 band graphic on L/R main mix outputs, easy to use and save to your library, FULL CONTROL OVER YOUR MIX (double tap the control to centre the fader).

    • Features:

      • 8 input, 6 Mic, 1 Stereo
      • Connect with any device with Wi-Fi or LAN
      • PHONE TABLET LAPTOP multi platform
      • 4 effect busses
      • Assignable footswitch input
      • Complete control from the front panel
      • analogue feel to operate
      • Balanced input and output sockets
      • Ultra compact
      • Professional features throughout

    • Specifications:

      • Inputs: 8 analogue input
      • MIC Input: 6 MIC/LINE COMBO XLR/JACK
      • LINE Input: 1 STEREO Jacks/3.5mm mini Jack
      • Master output: 2 Left/Right balanced XLR
      • Internal busses: 4 stereo FX / 1 mono AUX / stereo PFL / Main Mix
      • Stereo Monitor: 2 TRS Jack output
      • Headphone: 1 TRS Jack output
      • Control Interface: Full mix from 3 rotary encoders
      • Sample Frequency: 48 KHz
      • AD/DA: 48KHz, 24-bit
      • DSP: 40-bit float point, SHARC processor
      • Remote control: Cross platform Any device with Wi-Fi / Lan and web browser
      • Effects: 4 programmable DELAY and REVERB
      • USB Interface: 2 for playback/recording, scene storage and system updates
      • Network: yes via WIFI external module or RJ45 LAN connection
      • Power: 90-240V ~ 50/60Hz power supply 12VDC output
      • Weight: 17.63 Lbs

    • GTIN:

      5060255344750
