SmallHD MON-1703-P3X 703 P3X Full P3 Color Space 17-Inch Reference Monitor
  • SmallHD MON-1703-P3X 703 P3X Full P3 Color Space 17-Inch Reference Monitor
  • SmallHD MON-1703-P3X 703 P3X Full P3 Color Space 17-Inch Reference Monitor
  • SmallHD MON-1703-P3X 703 P3X Full P3 Color Space 17-Inch Reference Monitor
  • SmallHD MON-1703-P3X 703 P3X Full P3 Color Space 17-Inch Reference Monitor
  • SmallHD MON-1703-P3X 703 P3X Full P3 Color Space 17-Inch Reference Monitor
Questions? Ask a Markertek Expert:
800-522-2025 Email

SmallHD MON-1703-P3X 703 P3X Full P3 Color Space 17-Inch Reference Monitor

Manufacturer: SmallHD LLC

Item #: SMHD-MON-1703P3X   •   MFG #: MON-1703-P3X


Our Price:$3,999.00

free ship
Availability: Usually ships in 3-10 business days
This item is currently out of stock and will ship the minute we receive it – typically 3-10 business days. Need it sooner? Expedited delivery options may be available. Email [email protected] or call customer service at 800-522-2025 and we'll make it happen.



    The world's most rugged 17" monitor with astounding color accuracy, the MON-1703-P3X monitor is perfectly engineered for production and post-production use.

    Reference Grade Cinema Color
    Each 1703-P3 monitor comes pre-calibrated for DCI-P3 mastering, Covering 100% DCI-P3 with a Delta E average of 0.5. Easily install your own 3D LUT calibration with advanced color management solutions like Light Illusion's, LightSpace CMS, or SpectraCal's CalMAN. Load any 3D LUT via SD card using SmallHD's ColorFlow 3D LUT engine.

    Software That Eliminates Hardware
    Pagebuilder OS enables you to send your video signal downstream via the Output Preview page. Any LUTs applied to the Output Preview page will also be mirrored downstream. Easily convert HDMI/SDI signals with Cross Conversion.

    HD Scopes with Pixel Accurate Data Analysis
    Display up to three, fully customizable Scopes on screen at a time. Utilize Color Picker to show raw pixel values from the displayed video.

    Expose with Confidence
    Exposure Assist supports both ARRI and Spectrum based false color, with built in IRE guides for reference. Utilize 2x Zebra to warn you when reaching a brightness level of your choosing. This is great for matching exposure across shots and cameras.

    Dual View
    Monitor two input sources simultaneously. You can apply LUT's and tools to each source individually. Great for monitoring A/B cameras or pre and post LUT footage. You can also apply tools to each page individually.

    Custom Focus Assist & Peaking Tools
    Focus assist creates a bright highlight on in-focus subject matter; highly recommended when focusing on the fly. Focus Peaking increases the image sharpness allowing more detailed focusing. Change your color and intensity of your focus tools.

    Versatile Image Framing
    Select standard markers and safety areas that can be overlaid on the display as lines or matte overlays with custom opacity level and colors. Default aspect ratios include 4:3, 1.85, 2.39:1, 16:9 and Custom (user selectable).

    • Features

      • Durability: Rugged milled aluminum housing
      • VESA mounting 3/8" & 1/4" mounting points
      • Power options V-Mount, Gold Mount, AC power
      • LEMO Rapid Rail Quickly attach wireless devices & accessories Table to C-stand PageBuilder OS
      • All SmallHD on-camera monitors are equipped with the powerful and easy-to-use PageBuilder operating system
    • Specifications

      • Display
      • Panel Type: IPS LCD
      • Size Diagonal: 17 Inch
      • Resolution: 1920x1080
      • Pixel Density (PPI): 133 ppi
      • Aspect Ratio: 16:9
      • Active Area: 16.52
      • Brightness: 900 Nits
      • Contrast: 1400:1
      • Color Gamut: 100% DCI-P3
      • Color Depth: 10 bit
      • Viewing Angle: 178 degrees Vertical and Horizontal
      • Backlight Type: White LED
      • Adjustable Backlight: Yes - 0 - 100 in 6 steps with 100-nit studio mode
      • Temperature Adaptive Color: No
      • Input/Output Signal Types/Formats: 3G-SDI; HD-SDI; HDMI

        Connector Type
      • SDI: 2x 3G Inputs (BNC), 2x 3G Outputs (BNC)
      • HDMI: 1x Input, 1x Output
      • Audio: 1x 1/8" Headphone Jack on Front of Monitor
      • Power In: 1x AC Power Input - 3 Prong 90-260V, 1x XLR 4-pin Input 12-34VDC, 1x Lemo Output 12VDC @ 4A Max
      • Power Out: 1x Lemo Output 12VDC @ 4A Max
      • USB: 1x Front USB2, 2x Rear USB2

      • Primary Control Interface: Joystick Navigation, Dedicated Back Button. Additional Dedicated buttons for: LUT Selection; Backlight Level; Input Switch; Settings Menu; Multi View; Page 1-4 Instant Selection; Tools Menu
      • Record/Capture: Dedicated Capture Button on Front Bezel
      • Storage: SD Card for LUTs, Captured Images, Image Overlays, Firmware Upgrades, Profile Saving
      • USB: USB ports support storage devices for LUTs, Captured Images, Image Overlays, Profile Saving.

      • Connector Type: Single XLR 4-pin 12-34V DC IN for Battery or Power Supply, 12V Lemo 2-pin OUT MAX 2A
      • Voltage (DC): 12 - 34 VDC
      • Recommended Power Supply: Included
      • Overload Protection: Yes
      • Battery Types: Gold-Mount, V-Mount with optional Battery Plate Accessory
      • Output Voltage (VDC): 12V @ 2A via 2-pin Locking LEMO Connector

      • Compliance: FCC, IC, CE, RoHS
      • Operating Temperature: 32 - 100° F
      • Storage Temperature: 0 -104° F
      • Screen Protection: Optional Acrylic Screen Protector
      • Dimensions (H x W x D): 11.7" x 17" x 2.5"
      • Weight (Item Only without battery): 12.0625lb
    • Item Includes

      • 3 Foot HDMI to HDMI Cable
