SmallHD ULTRA 5 Inch Smart Touchscreen Monitor with 3000nits - 1920x1080

ITEM #: SMHD-ULTRA-5 MFG #: 16-0527

Primary Image
  • Product Image Thumbnail 1 of 5
  • Product Image Thumbnail 2 of 5
  • Product Image Thumbnail 3 of 5
  • Product Image Thumbnail 4 of 5
  • Product Image Thumbnail 5 of 5
Free Shipping with $49 Minimum Order

Item unavailable. Please select another option.

Ask a Markertek Expert if you need assistance finding an appropriate substitute.

Our Price:

$2,199.00

Availability: Typically Ships in 3-10 Business Days
iAvailability Description Popup


    16-0527 - Overview

    Powerful, portable, and adaptable, the Ultra 5 offers a dazzling 3000nits brightness and a full suite of large front-facing custom-function buttons for maximum control in all conditions. Experience all your favorite PageOS 5 tools, functions, and settings pages on a fully-loaded 5-inch touchscreen monitor.

    Ultra 5 is designed for the user who wants it all, including optional Gold or V-Mount Micro Battery Plates (Not included) for a compact power solution and an Ethernet port to enable ARRI and Sony VENICE Camera Control (Camera Control license and cable sold separately).

    Camera Control for ARRI, RED® and Sony VENICE

    Transform your touchscreen into the central command hub of your camera. SmallHD’s proprietary software enables unfettered access to ARRI, RED DSMC2, KOMODO® V-RAPTOR™ and Sony VENICE camera functions and project settings such as Start/Stop Record, FPS, Shutter Speed, ISO, Color Temperature/White Balance, Clip Playback, and more. *Individual Camera Control software licenses are sold separately.

    • Features:

      • Display: 5-inch Touchscreen, 1920x1080, 440 PPI
      • Input: 1x 3G-SDI [IN], 1x HDMI 2.0 (4Kp30) [IN]
      • Output: 1x 3G-SDI [IN/OUT], 1x HDMI 2.0 (4Kp30) [OUT], 1x 3.5mm Stereo Headphone Jack
      • Power Input: 2-pin Locking Power Input (10-34V DC, 2.1A)
      • Data I/O: 1x SD Card Slot, 1x RJ45 Ethernet, 1x Micro USB, 1x Locking USB

    • Specifications:

      • Environmental
      • Mount Points: 6x 1/4-20 Mounting Points

        Display
      • Panel Type: Touch-Screen
      • Resolution: 1920 x 1080
      • Aspect Ratio: 16:9
      • Brightness: 3000nits
      • Backlight Type: Edgelit

        Input Signal
      • 3G-SDI Input Types: 1x 3G-SDI

        Output Signal
      • HDMI Output Types: 1x HDMI 2.0 (4Kp30)

        Connector Type
      • SDI: 1x 3G-SDI (In), 1x 3G-SDI (In/Out)
      • HDMI: 1x HDMI 2.0 (4Kp30) [In], 1x HDMI 2.0 (4Kp30) [Out]
      • Audio: 1x 3.5mm Stereo Headphone Jack

        Data I/O
      • Connector Type: 1x RJ45 Ethernet
      • Storage Media: 1x SD Card Slot
      • USB: 1x Micro USB 1x Locking USB

        Power
      • Input: 2-pin Locking Power Input (10-34V DC, 2.1A)

        Software
      • Pixel Zoom: Yes
      • Focus Assist: Yes
      • Peaking: Yes
      • False Color: Customizable False Color Overlays
      • Waveform: Customizable 4K Waveform w/Region of Interest Highlighting (Coming Soon)
      • Custom LUTS: 17pt 3D-LUT on Output/Input 33pt 3D-LUT on Output/Input

    • GTIN:

      0811786033461
