Sony BRCX400 IP 4K Pan-Tilt-Zoom Camera With NDI®/HX - Black

ITEM #: SNY-BRCX400 MFG #: BRCX400

Primary Image
  • Product Image Thumbnail 1 of 5
  • Product Image Thumbnail 2 of 5
  • Product Image Thumbnail 3 of 5
  • Product Image Thumbnail 4 of 5
  • Product Image Thumbnail 5 of 5
Free Shipping with $49 Minimum Order

Item unavailable. Please select another option.

Ask a Markertek Expert if you need assistance finding an appropriate substitute.

List Price:

$7,134.40

Our Price:

$5,783.93

Availability: Usually Ships in 5-14 Days.
Please Email, Chat or Call (800) 522-2025 for Detailed Delivery Info
iAvailability Description Popup


    BRCX400 - Overview

    Capture every point of view in 4K with excellent picture quality and efficient IP production workflow
    The versatile Sony BRC-X400 PTZ camera is ideal for use in a wide range of environments-from broadcast studios and remote on-air suites to sports stadiums, arenas, houses of worship and lecture halls.

    The camera's 1/2.5-type Exmor RT sensor captures broadcast-quality 4K images with excellent sensitivity, very low noise and rich, natural color reproduction. It's complemented by the integrated high-resolution lens that offers a powerful zoom capability of up to 80x in Full HD** (30x in 4K), with an expansive approx. 70° wide angle coverage to capture every point of view.

    Efficient IP-based live production is augmented with support for NDI®|HX (via optional license), allowing flexible configuration with other networked NDI-enabled devices.

    Images can also be reviewed remotely via a web browser, with support for RTSP (Real Time Streaming Protocol) ensuring smooth, stable streaming of video plus audio (from an optional microphone, available separately) over an IP network.

    Installation and set-up is easy, with a new Picture Setting File*** allowing the same settings to be applied to multiple cameras through a web interface from a laptop or PC. Convenient integration in multi-camera live events is also simplified with genlock support and an "on-air" tally lamp.

    Please Note:
    *NDI® is a registered trademark of NewTek, Inc.
    **With Clear Image Zoom and Tele Convert Mode
    ***Requires firmware V2.00

    • Features:

      • Excellent 4K Images, Even in Low Light
      • Up to 80x Zoom
      • Wide Viewing Angle
      • Support for NDI®*|HX
      • Multiple Control Protocols
      • Remote Viewing
      • Simpler Installation, Lower Costs
      • Ideal for Live Production
      • Fast, Fuss-Free Setup
      • Simplified Construction of VR/AR Systems*

    • Specifications:

      • Camera
      • Image Sensor: 1/2.5 Exmor R CMOS
      • Image Sensor (Number of Effective Pixels): Approx. 8.5M pixels
      • Signal System:
        - 2160/29.97p, 25p, 23.98p
        - 1080/59.94p, 50p, 29.97p, 25p, 23.98p
        - 1080/59.94i, 50i
        - 720/59.94p, 50p
      • 4K Capability: Yes (built-in 4K functions)
      • Minimum Illumination (50IRE): 1.6 lux (1/30s 50IRE F2 high-sensitivity OFF)
      • Horizontal Resolution: 1700 TV lines (Center) (4K) 1000 TV lines or higher (Center) (FHD)
      • Gain: Auto/Manual (0 to +48 dB) (High Sensitivity On)
      • Shutter Speed:
        - 1/1 to 1/10000 sec (59.94 Hz system)
        - 1/1 to 1/10000 sec (23.98 Hz system)
        - 1/1 to 1/10000 sec (50 Hz system)
      • Exposure Control: Auto, Manual, Priority AE (Shutter, Iris)
      • White Balance: Auto1, Auto2, One Push WB Indoor, Outdoor, Manual
      • Zoom Capability: 30x (4K with CIZ), 40x (HD with CIZ), Max. 80x (HD with CIZ* and Tele Convert Mode) *CIZ = Clear Image Zoom
      • Focusing System: Auto/Manual
      • Horizontal Viewing Angle: Approx. 70° (Wide)
      • Focal Length: f=4.4 mm (Wide) to 88.0 mm (Tele) F2.0 to F3.8
      • Minimum Object Distance: 80 mm (Wide) 800 mm (Tele)
      • Pan/Tilt Angle:
        - Pan: ±170°
        - Tilt: +90°/-20°
      • Pan/Tilt Speed (Max.):
        - Pan: 300°/s
        - Tilt: 126°/s
      • Pan/Tilt Speed:
        - Pan: 1.1° - 101°/s
        - Tilt: 1.1° - 91°/s
      • Pan/Tilt Speed (Slow):
        - Pan: 0.5° - 60°/s
        - Tilt: 0.5° - 60°/s
      • Pan/Tilt Slow Mode: Yes
      • Pan/Tilt Operation Noise: NC30 or less* *Sony measurement conditions
      • Preset Position: 256 (CGI) 100 (VISCA)
      • Picture Freeze Preset: Yes
      • Preset Mode1/Mode2: Yes
      • PTZ Trace Memory: Yes
      • PTZ Motion Sync: Yes
      • Camera Tracking Data Output: Yes (Requires firmware V2.10)

        Interfece
      • 4K Video Output:
        - 1x HDMI
        - 1x IP (streaming)
      • HD Video Output:
        - 1x 3G-SDI
        - 1x HDMI
        - 1x IP (streaming)
      • Remote Video Format Switching: Yes
      • HDMI Color Space:
        - YCbCr, 4:2:2 8 bit
        - RGB, 4:4:4 8 bit
      • Camera Control Interface:
        - VISCA RS-422 RJ45 (In/Out)
        - VISCA over IP RJ-45
        - S700PTP RJ-45
      • IR Remote Control: Yes
      • Microphone Input: Mini-phone (Φ3.5mm) x2 (Mic/Line Selectabe)
      • Sync. System: EXT/INT
      • External Sync. Input: BNC, 75O, HD 3-level sync, SD Black Burst
      • Tally: 1x Front
      • Power Connector Type: IEC60130-10 (JEITA standard RC-5320A) TYPE4

        General
      • Power Requirements: DC 12V (DC 10.8 to 13.2V), PoE+ (IEEE802.3at compliant)
      • Power Consumption: 25.5 W Max.
      • Operating Temperature: 32°F - 104°F (0°C - 40°C)
      • Storage Temperature: -4°F - 140°F (-20°C - 60°C)
      • Dimensions (WxHxD): 6" x 7" x 8" (158mm x 177mm x 200mm)
      • Mass *1: Approx 3.97lbs (1.8kg)
      • Camera Body Color: White/Black
      • Size of Screw Hole for Tripod: 1x 1/4-20UNC
      • Mountable Angle: < ±15°
      • Ceiling Mount: Yes

    • Item Includes:

      • 1x AC power adapter
      • 1x IR Remote Commander Unit
      • 2x Ceiling bracket
      • 1x Wire rope
      • 8x Screw M3
      • 6x Screw M2.6 Black
      • 1x HDMI cable fixing plate

    • Warranty:

      • 2-Year Limited Warranty

    • GTIN:

      0027242918061
