StarTech ST121USBHD 165 ft HDMI Extender with 4-Port USB Hub - 1080p

ITEM #: ST-ST121USBHD MFG #: ST121USBHD

Primary Image
  • Product Image Thumbnail 1 of 3
  • Product Image Thumbnail 2 of 3
  • Product Image Thumbnail 3 of 3
Free Shipping with $49 Minimum Order

List Price:

$213.99

Our Price:

$213.70

Availability: Ships Factory Direct, Typically in 3-10 Business Days
iAvailability Description Popup


    ST121USBHD - Overview

    This HDMI extender kit lets you transmit your 1080p HD video source to your remote HDMI display at distance of up to 165 ft. away (50 m) using shielded CAT6 cabling. The extender features a built-in 4-port USB 2.0 hub that also lets you connect four remote USB peripheral devices at your display location.

    Crystal-clear picture quality
    Using this HDMI extender, you can maintain the quality of your high-definition video signal along with the accompanying 7.1 digital audio, even at 165 feet away from your source device. The extender supports resolutions up to 1920x1200 or 1080p - perfect for dazzling your audience in remote digital-signage applications in hospitals or at shopping centers.

    Hassle-free remote USB integration
    The built-in 4-port USB 2.0 hub lets you remotely connect, access or control up to four USB devices located at your remote display - great for flash drives, printers, scanners, external hard drives and I/O devices. Remote USB extension also enables you to remotely control your source device, which is ideal for adding touchscreen interfaces at your display in market or POS kiosks.

    Easy installation and setup
    For hassle-free setup the HDMI extender offers easy plug-and-play installation with no additional software or drivers required. Plus, the extender passes the EDID information included in your HDMI signal, and automatically adjusts video equalization ensuring you won’t have to configure it manually. Mounting hardware is also included, for a tidy and professional installation.

    Note: To maximize performance this extender requires shielded CAT6 cable. When using unshielded CAT6 cable the maximum distance is reduced to 30m. When using CAT5 cable the maximum distance is reduced to 15m.

    The ST121USBHD is backed by a 2-year StarTech.com warranty and free lifetime technical support.

    • Features:

      • Crystal-clear picture quality, with support for uncompressed 1920x1200 or 1080p HD video extension
      • Easy remote peripheral integration, with a built-in 4-port USB hub
      • Tidy, professional installation using the included mounting hardware
      • Extends HDMI video and four USB peripheral devices up to 165 ft
      • Supports CAT5e and CAT6 Ethernet cable
      • HDMI transmitter and receiver included

    • Specifications:

      • Connector A: HDMI (19 pin) Female Input
      • Connector A: USB Mini-B (5 pin) Female
      • Connector B: HDMI (19 pin) Female Output
      • Connector B: USB A (4 pin) Female
      • Connector B: USB Mini-B (5 pin) Female
      • Humidity: 0% - 80 % RH (non-condensing)
      • Operating Temperature: 0°C to 40°C (32°F to 104°F)
      • Storage Temperature: -10°C to 60°C (14°F to 140°F)
      • Audio: Yes
      • Cabling: Cat 5 UTP or better
      • Daisy-Chain: No
      • Ports: 1
      • Shipping (Package) Weight: 0.1 kg [0.3 lb]
      • Audio Specifications: Supports Dolby TrueHD, DTS-HD MA
      • IR Interface: IR Interface: Bi-directional
      • 38Khz / ±10° / 5M
      • Max Distance: 80 m / 260 ft
      • Maximum Data Transfer Rate: HDMI - 3.4Gbps
      • RS232 - 115200bps baud
      • Maximum Digital Resolutions: 1080p @ 60Hz, 48-bit
      • Wide Screen Supported: Yes
      • Output Current: 1 A
      • Output Voltage: 5 DC
      • Plug Type: N
      • Power Source: AC Adapter Included
      • Included in Package: Ethernet cables
      • Included in Package: HDMI over CAT6 receiver
      • Included in Package: HDMI over CAT6 transmitter
      • Included in Package: mounting kit
      • Included in Package: quick install guide
      • Included in Package: universal power adapter (NA/EU/UK/AU)
      • Included in Package: USB to Mini-USB cable

    • Item Includes:

      • HDMI over CAT6 transmitter
      • HDMI over CAT6 receiver
      • Ethernet cables
      • USB to Mini-USB cables
      • universal power adapter (NA/EU/UK/AU)
      • mounting kit
      • quick install guide

    • GTIN:

      0065030862363
