Symetrix W3 STANDARD IP Remote with Push Button Rotary Encoder - 4-Buttons - 2 OLED Displays - PoE - Single Gang - Black

ITEM #: SYX-W3BKSTANDARD MFG #: 80-0170

Primary Image
Free Shipping with $49 Minimum Order

We are an authorized dealer for this series; however, the manufacturer does not permit online sales. Please contact a sales engineer at 1-800-522-2025 to complete your purchase.

Availability: Ships Factory Direct, Typically in 3-10 Business Days
iAvailability Description Popup


    80-0170 - Overview

    With an OLED display and dedicated knobs and buttons, the Symetrix W-Series provide standard IP communication over Ethernet creating a single standardized infrastructure.

    Available in four configurations, the controls of the W Series may be used for source selection, volume, mute, and preset recalls for any Composer™ based Symetrix DSP.

    Series Features:
    -IP and PoE based controllers
    -User-programmable displays for labeling and feedback
    -Configurations available in US and EU form factors
    -Simple and easy end-user control of the business audio system
    -Ideal for Houses of Worship, Hospitality, Education, Performance/Live Sound, and Conferencing Spaces
    -W-Series remotes have set a new standard for IP controllers in terms of both functionality and overall construction quality.
    -W1 Features a push button encoder and display. The encoder can operate in a continuous (as in a volume control) fashion. The push button can toggle a binary or momentary action (as in a mute or preset recall) or toggle between two encoder assignments.

    • Features:

      • Simple deployment with standard PoE switch
      • Features a push button encoder, four buttons, and display
      • Available in US or EU single gang form factors and black or white finishes
      • Supports standard single gang Decora faceplates

    • Specifications:

      • W3
      • User Interface: One rotary encoder with push-button knob and 4 push-button switches
      • Form Factor: 1 or 2-gang US or EU wall mount.
      • Device Width (US): 1.78" Single Gang Decora
      • Device Depth (US): 1.34"
      • Device Height (US): 4.25"

        Display
      • Type: High Contrast OLED
      • Viewable Area: .91" ( 23.11mm) and 1.3" (33.02mm) Diagonal
      • Orientation: Vertical

        System
      • Physical Network Layer: Ethernet
      • Ethernet Cable Standard: CAT5e/6, maximum device-to-device length = 100 meters
      • Compatibility: Symetrix Composer-managed products
      • Maximum Devices: 128 units per site file

    • Item Includes:

      • W Series device.
      • A single or dual-gang black or white
      • Decora® wall plate (as applicable).
      • Two or four #6-32 x 5/8" screws or two
      • M3x0.5x30mm slotted screws (as applicable).
      • Quick Start Guide.

    • Warranty:

      • 5 years
