Teradek Bolt 4K LT HDMI 750 10-bit 4K30p HDR Wireless Video Transmitter/Receiver Kit - Gold Mount

ITEM #: TER-B4KLTH750TRG MFG #: BOLT 4K LT HDMI 750 TX/RX GOLD MOUNT

Primary Image
  • Product Image Thumbnail 1 of 5
  • Product Image Thumbnail 2 of 5
  • Product Image Thumbnail 3 of 5
  • Product Image Thumbnail 4 of 5
  • Product Image Thumbnail 5 of 5
Free Shipping with $49 Minimum Order


Item unavailable.Please select another option.

Ask a Markertek Expert if you need assistance finding an appropriate substitute.

(800) 522-2025Email


Availability: Sold Out
iAvailability Description Popup


BOLT 4K LT HDMI 750 TX/RX GOLD MOUNT - Overview

The Bolt 4K LT HDMI is an HDMI-only, zero-delay wireless video solution designed for longterm compatibility across our entire Bolt 4K ecosystem, so that as your production grows your Bolt 4K family will too. It supports 10-bit HDR video up to 4K30p with a line-of-sight range up to 750 feet (228 meters).

Key features of the Bolt 4K LT HDMI Kit include a BB3 Wireless Chipset, which allows for 4K HDR transmission, better image quality at all resolutions, stronger link robustness, and pairing of up to 6 receivers. With the kit you'll get zero image-delay for critical focus-pulling, an HDMI loop out, a ruggedized aluminum-unibody chassis, stable connectivity, and fast reconnection times. Additionally, this Teradek product transmits audio and timecode and has ultra-fast pairing and intuitive setup with the Bolt Manager App. Its enhanced AES-256 encryption prevents unauthorized access.

The Bolt 4K LT HDMI Kit is built with aircraft-grade aluminum for a field-ready, lightweight form factor with ¬-20 and M3 mounting points. This product is designed for filmmakers and creators with small camera setups who want professional performance that's reliable, vivid, and durable.

This set includes a Bolt 4K LT HDMI 750 TX, Bolt 4K LT HDMI 750 RX, and the choice of a Gold Mount, V-Mount, or no battery plate.

  • Features:

    • Supports 10-bit 4K30p HDR video up to 750 ft.
    • Zero-Delay wireless video (<0.001sec)
    • Inputs: HDMI 2.1
    • Outputs: HDMI 2.1, includes HDMI Loop Out

  • Specifications:

    • Bolt 4K LT HDMI 750 TX
    • Video Inputs: 1x HDMI 1.4b Type-A receptacle
    • Video Outputs: 1x HDMI 1.4b Type-A receptacle
    • Color Sampling: YCbCr 4:2:2 10-Bit, RGB 4:4:4, 8-bit
    • Delay Tx To Rx: <0.001sec
    • Supported Resolutions: 4Kp23.98/24/25/29.97/30/50/59.94/60, 1080p 23.98/24/25/29.97/30/50/59.94/60, 1080psf23.98/24/25/29.97/30, 1080i50/59.94/60, 720p50/59.94/60, 480p50, 576p59.94/60, 480i(NTSC)/576i(PAL)
    • Video Compression: Visually lossless
    • Audio Compression: 48kHz 24-bit PCM
    • Audio Input: Embedded HDMI Audio Input (2 channel)
    • Configuration Interfaces: OSD Screen with Menu, Joystick Navigation
    • Switches: On/Off Switch
    • Mobile App: Bolt App
    • Desktop App: Bolt Manager application for OSX & Windows
    • Usb Interface Functionality: Upgrade Via Micro-USB, 5-pin Locking Connector CCU
    • Bluetooth: 2.4 GHz
    • Network Antennas: 2x External 2dBi antennas (included)
    • Wireless: DFS Frequencies: 5.270 ~ 5.670 GHz, Non-DFS Frequencies: 5.190 ~ 5.230 GHz and 5.755 ~ 5.795 GHz
    • Rf Channel Selection: Auto, Manual
    • Encryption: AES-256, RSA-1024 key exchange
    • Rf Power: 19 dbm EIRP (2x external 2dBi antennas; <80mW transmit power)
    • Range: Up to 750 ft line of sight
    • Unicast Multicast: TX transmits video to up to 6 receivers
    • Power Input: 2-Pin Circular locking connector 6-28 VDC
    • Battery: None, optional Sony/Canon dual battery plate
    • Nominal Power Consumption: 9 Watts
    • Operating Temperature: 0~40 deg-C
    • Dimensions: 2.4" x 4.1" x 1.3"
    • Weight: 7.3oz

      Bolt 4K LT HDMI 750 RX
    • Video Outputs: 1x HDMI 1.4b Type-A receptacle
    • Color Sampling: YCbCr 4:2:2 10-Bit, RGB 4:4:4, 8-bit
    • Delay Tx To Rx: <0.001sec
    • Supported Resolutions: 4Kp23.98/24/25/29.97/30/50/59.94/60, 1080p 23.98/24/25/29.97/30/50/59.94/60, 1080psf23.98/24/25/29.97/30, 1080i50/59.94/60, 720p50/59.94/60, 480p50, 576p59.94/60, 480i(NTSC)/576i(PAL)
    • Video Compression: Visually lossless
    • Test Pattern Generator Support: Yes
    • Audio Compression: 48kHz 24-bit PCM
    • Audio Output: Embedded HDMI Audio Input (2 channel)
    • Configuration Interfaces: OSD Screen with Menu, Joystick Navigation
    • Switches: On/Off Switch
    • Mobile App: Bolt App
    • Desktop App: Bolt Manager application for OSX & Windows
    • Usb Interface Functionality: Upgrade Via Micro-USB, 5-pin Locking Connector CCU
    • Bluetooth: 2.4 GHz
    • Network Antennas: 5x External 2dBi antennas (included)
    • Wireless: DFS Frequencies: 5.270 ~ 5.670 GHz, Non-DFS Frequencies: 5.190 ~ 5.230 GHz and 5.755 ~ 5.795 GHz
    • Rf Channel Selection: Auto, Manual
    • Encryption: AES-256, RSA-1024 key exchange
    • Rf Power: 17 dbm EIRP (1x external 2dBi antenna; <51mW transmit power)
    • Range: Up to 750 ft line of sight
    • Unicast Multicast: Pair up to 4 transmitters per receiver
    • Noise Rejection: Can coexist with Wi-Fi and 5GHz cordless phones, and can operate up to 6 sets in same location
    • Interoperability: Can transmit wireless video to all ranges of Bolt 4K XT and Bolt 4K LT receivers (limited by shortest range device)
    • Power Input: 2-Pin Circular locking connector 6-28 VDC
    • Battery: None, optional Sony/Canon dual battery plate
    • Nominal Power Consumption: 11 Watts
    • Operating Temperature: 0~40 deg-C
    • Dimensions: 4.8" x 3.7" x 1"
    • Weight: 10.3oz

  • Item Includes:

    • 1x Bolt 4K LT HDMI 750 TX
    • 1x Bolt 4K LT HDMI 750 RX Gold Mount
    • 1x Hot Shoe Adaptor
    • 1x Lightstand Adapter 1/4-20in
    • 1x (Bit 118) 2pin Conn. to PowerTap - 18in Cable
    • 1x USB 2.0 Type A Male to USB Type C Male - 1m Cable
    • 2x Ultra Thin HDMI Male Type A (Full) - HDMI Male Type A (Full) 18in Cable
    • 1x PSU 2pin Conn. to 18W AC Adapter (Int) - 6ft Cable
    • 7x Antenna 2dBi WIFI 2.4/5.8GHz (Small Antenna)
    • 1x Teradek Standard Terms and Conditions
    • 1x Insert - Product Register
    • 1x Insert - Bolt 4K Firmware Update
    • 1x QR Code Insert - Bolt 4K LT 750 HDMI
    • 1x Bolt 4K LT RX Battery Cover (Machined Anodized)
    • 1x Screw Flat Head Phillips Black
    • 1x (Bit 118) 2pin Conn. to PowerTap - 18in Cable
