Tripp Lite PS615HG20AOEM For Patient-Care Vicinity - UL 1363A Medical-Grade Power Strip - 15 Foot Cord

ITEM #: TRL-PS615HG20AOE MFG #: PS615HG20AOEM

Primary Image
  • Product Image Thumbnail 1 of 3
  • Product Image Thumbnail 2 of 3
  • Product Image Thumbnail 3 of 3
Free Shipping with $49 Minimum Order

List Price:

$226.04

Our Price:

$170.00

Availability: Typically Ships in 3-10 Business Days
iAvailability Description Popup


    PS615HG20AOEM - Overview

    The PS615HG20AOEM Medical-Grade Power Strip supplies power to movable plug-connected components mounted to a rack, table or pedestal in operating rooms, patient-care areas, therapy rooms, imaging environments and administrative areas. Compliant with UL 1363A specifications, this 120V, 50/60 Hz power strip features a NEMA 5-20P-HG hospital-grade plug and six NEMA 5-20R-HG hospital-grade outlets. Two resettable built-in 20A circuit breakers control power to all outlets and protect the power strip against overloads.

    Switchless design prevents the unit from being accidentally shut off. Locking safety covers are integrated to protect unused outlets from debris and damage. Long 15-foot 20A AC power cord gives you flexibility to roll the equipment where it’s most needed. Mounting tabs and flanges let you install the PS615HG20AOEM on a wide variety of surfaces, such as IV poles, mobile carts, crash carts and mobile medical workstations. All-metal housing ensures safety and is guaranteed to last a long time in demanding environments.

    • Features:

      • Power Distribution in Any Medical Facility
      • Ideal for operating rooms, administrative areas, patient-care areas, therapy rooms and imaging environments
      • Attaches easily to IV poles, mobile carts, crash carts and mobile workstations
      • 120V, 50/60 Hz power strip complies with UL 1363A specifications Versatile Medical-Grade Solution
      • Six NEMA 5-20R-HG hospital-grade outlets provide consistent power
      • Long 15-foot 20A AC power cord with NEMA 5-20P-HG hospital-grade plug lets you move the components where power is most needed
      • Rugged all-metal housing for long life in demanding environments Premium Safety Features
      • Dual resettable built-in 20A circuit breakers protect against dangerous overloads
      • Switchless design prevents accidental shutoff
      • Integrated locking safety covers keep debris away from unused outlets Ready to Use Right from the Box
      • Mounting tabs and flanges let you install the unit on a wide variety of surfaces

    • Specifications:

      • Frequency Compatibility: 50 / 60 Hz
      • Output Receptacles: (6) 5-20R-HG
      • Circuit Breaker (amps): 20
      • Overload Protection: 2 x 20amp breaker (1 line, 1 neutral)
      • Outlet Orientation: Single row of 6
      • Right-Angle Outlets: No
      • Nominal Input Voltage(s) Supported: 120V AC
      • Recommended Electrical Service: 20A, 120V
      • Input Connection Type: NEMA 5-20P-HG
      • Input Cord Length (ft.): 15
      • Input Cord Length (m): 4.57
      • Input Cord Gauge Type: 12 gauge, SJT
      • Voltage Compatibility (VAC): 120
      • Switches: No power switch
      • Shipping Dimensions (hwd / in.): 15 x 6 x 3.55
      • Shipping Dimensions (hwd / cm): 38.1 x 15.24 x 9.02
      • Shipping Weight (lbs.): 3.55
      • Shipping Weight (kg): 1.61
      • Unit Dimensions (hwd / in.): 13.75 x 2.5 x 1.5
      • Unit Dimensions (hwd / cm): 34.93 x 6.35 x 3.81
      • Unit Weight (lbs.): 2.25
      • Unit Weight (kg): 1.02
      • Material of Construction: Metal
      • Integrated Keyhole Mounting Tabs: Keyhole mounting tabs and flanges enable mounting to a variety of surfaces
      • Receptacle Color: White
      • Color (AC Line Cord): White
      • Outlets Measurement (Center to Center): 38.7mm
      • Keyhole Slot Mounting Measurement (Center to Center): Distance between end tabs = 330.20mm
      • Additional International Approvals: TUV tested to UL 1363A
      • Product Warranty Period (Worldwide): Lifetime limited warranty

    • Item Includes:

      • PS615HG20AOEM UL 1363A Medical-Grade Power Strip with 6 20A Hospital-Grade Outlets
      • Owner’s Manual with maintenance requirements

    • Warranty:

      • Lifetime

    • GTIN:

      0037332190680
