West Penn 4246EZBL1000 Cat 6 Cable 23 Gauge 4 Pair 23AWG UTP CMR - Blue - 1000 Feet

    Questions? Ask a Markertek Expert:
    800-522-2025 Email

    West Penn 4246EZBL1000 Cat 6 Cable 23 Gauge 4 Pair 23AWG UTP CMR - Blue - 1000 Feet

    Manufacturer: West Penn Wire Corp

    Item #: WP-4246EZBL1000   •   MFG #: 4246EZBL1000



    List Price:$212.20
    Our Price:$191.42

    free ship


    Availability: Direct Ship From Manufacturer
    i
    Item ships directly from the manufacturer and is subject to manufacturer availability. We will contact you with expected availability. You can also email [email protected], chat or call customer service (800)-522-2025 for expedited delivery options.


    • 2 - 7 Day Normal Delivery Time - Faster Shipping Options at Checkout or Call Us.


    Share!





    23 AWG.- 4 PAIR Solid bare copper conductors.

    APPLICATION: Indoor - Category 6 Applications- Ethernet, IP Cameras, Digital Integration, DVI, HDMI
    Meets or exceeds TIA/EIA 568C.2 Category 6 Specifications


    • Specifications

      • Conductor
      • Number Of Pairs: 4
      • AWG Size: 23
      • Conductor Stranding: Solid
      • Conductor Type: Bare Copper
      • Nominal DCR: 24 Ohm/1000ft
        Insulation and Shielding
      • Insulation Type: Polyolefin
      • Insulation Color Code: 1.Blue,WH-Blue 2.Orange,WH-Orange 3.Green,WH-Green 4.Brown, WH-Brown
      • Shield Type: Unshielded Twisted Pair (UTP)
        General
      • Total Number of Conductors: 8
      • Jacket Type: PVC
      • Nominal Cable O.D.: 0.22 in
      • Plenum: No
      • NEC UL Rating: CMR
      • RoHS Compliant: Yes
      • ANSI/TIA Category: Category 6 TIA/EIA 568C.2
      • TIA Test: ANSI/TIA-568-C.2
      • Pull Tension: 40 lbs
      • Bend Radius: 1.1 in
      • Cable Weight: 29 lbs
        Electrical
      • Nominal Velocity of Propagation (VP): 72 %
      • Delay Skew: 45 ns/100m
      • UL Flammability: UL1666 Vertical Shaft
      • CSA Flammability: FT4
      • Operating Range: -0 to 75 Deg C
      • UL Voltage Rating: 300
      • Nominal Impedance: 100 Ohm
      • Nominal Capacitance Between Conductors: 15 pF/ft
