Whirlwind PCDIHW Direct Box Dual with RCA 1/4 Inch Inputs 1/8 Inch Hardwired Input Tail 30 Inch

ITEM #: WW-PCDI-HW MFG #: PCDI-HW

Primary Image
  • Product Image Thumbnail 1 of 3
  • Product Image Thumbnail 2 of 3
  • Product Image Thumbnail 3 of 3
Free Shipping with $49 Minimum Order

List Price:

$235.69

Our Price:

$214.00

Availability: In Stock
iAvailability Description Popup


    PCDI-HW - Overview

    The Whirlwind pcDIhwb is a PCDI with a hard wired tail terminated with a stereo 3.5mm plug, perfect for interfacing the outputs of CD players, computer sound cards, iPODs / MP3 players, tape decks, etc. with professional, balanced, low impedance equipment (with no chance of losing the cable).

    This unit contains two separate DIs - input your signals with one hard wired, 30 inch 3.5mm (1/8") mini TRS stereo plug, two sets of color coded RCA phono type input and through jacks or 1/4" TS input jacks. Output is via corresponding color coded XLRs.

    • Features:

      • Color coded RCA phono in / through jacks
      • 3.5 mm input plug on a 30" hard wired cable
      • 1/4" TS input jacks
      • Color coded XLR output jacks
      • Ground Lift switch to help eliminate hum and buzz
      • Stereo/Mono switch for stereo operation or safely combine both inputs into a mono signal sent to both outputs
      • 20dB pad switch for connection to "hot" input signals
      • Uses Whirlwind's TRHL-M transformers with metal shield

    • Specifications:

      • Impedance Ratio (input to output, per channel): 133:1
      • Frequency Response: 20Hz-20kHz ±1dB
      • Level Change (input to output): -20dB (pad out), -40dB (pad in)

    • GTIN:

      0692465023207
