Alfatron ALF-12X-CAM 1080P HD PTZ Camera with a 12x Zoom Lens

ITEM #: ALF-12X-CAM MFG #: ALF-12X-CAM

  • Product Image Thumbnail 1 of 3
  • Product Image Thumbnail 2 of 3
  • Product Image Thumbnail 3 of 3
free ship

List Price:

$1,420.00

Our Price:

$1,349.99

Availability: Ships Factory Direct, Typically in 3-10 Days
iAvailability Description Popup


    ALF-12X-CAM - Overview

    The Alfatron ALF-12X-SDIC is a 1080P HD PTZ camera with a 12x Zoom Lens, equipped for a high-quality video stream and high definition real-time synchronization. This PTZ camera is suitable for medium to large-sized meeting rooms, boardrooms, conference venues, and houses of worship.

    • Features:

      • 1080P HD PTZ Camera
      • 12X Optical Zoom
      • 2.07MP Sensor
      • Automatic focus, aperture, shutter, white balance
      • Video over POE Ethernet, HDMI, & USB
      • Remote control via RS232, RS485
      • IR remote control

    • Specifications:

      • Sensor: 1/2.8-inch-high quality HD CMOS sensor
      • Effective Pixels: 16: 9 2.07 megapixel
      • HDMI/ Video Format:
        1080P60/50/30/25/59.94/29.97
        1080I60/50/59.94
        720P60/50/30/25/59.94/29.97
      • Interface Video Format:
        1920X1080P60/50/30/25
        1280X720P60/50/30/25
        960X540P30
        640X360P30
        640X480P30
        352X288P30
        960X540P30
      • Optical Zoom: 12X, f3.946.1mm
      • View Angle: 6.3°tele, 72.5°wideAV:F1.8 – F2.4
      • Digital Zoom: 10X
      • Minimum Illumination: 0.5Lux (F1.8, AGC ON)
      • DNR: 2D & 3D DNR
      • White Balance: Auto / Manual/ One Push/ 3000K/ 4000K/5000K/6500K
      • Focus: Auto/Manual
      • Aperture: Auto/Manual
      • Electronic Shutter: Auto/Manual
      • BLC: ON/OFF
      • WDR: OFF/ Dynamic level adjustment
      • Video adjustment: Brightness, Color, Saturation, Contrast, Sharpness, B/W mode, Gamma curve
      • SNR: >55dB
      • Video Interfaces: USB2.0, USB3.0, HDMI, LAN, RS232?input?
      • Image code stream: Double streams output simultaneously
      • Video Compression Format: H.264, H.265
      • Control Signal Interface: RS-232 Ring through RS232 output, RS-485
      • Control Protocol: VISCA/Pelco-D/Pelco-P; Baud Rate: 115200/9600/4800/2400bps
      • Audio Input Interface: Double track 3.5mm linear input
      • Audio Compression Format: AAC/MP3/PMC Audio compression
      • HD IP Interface: 100M IP port(100BASE-TX); 5G WiFi (optional), support IP Visca control protocol
      • Network Protocol: RTSP/RTMP,ONVIF
      • Power Interface: HEC3800 outlet (DC12V)
      • Pan Rotation: ±170°
      • Tilt Rotation: -30°?+90°
      • Pan Control Speed: 0.1 -180°/sec
      • Tilt Control Speed: 0.1-80°/sec
      • Preset Speed: Pan: 60°/sec, Tilt: 30°/sec
      • Preset Number: 255 presets (10 presets by the remote controller)
      • Supply Adapter: AC110V-AC220V to DC12V/2A
      • Input Voltage: DC12V±10%
      • Input Current: 1A(Max)
      • Consumption: 12W (Max)
      • Store Temperature: -10°C to +60°C
      • Store Humidity: 20% – 95%
      • Working Temperature: -10°C to +50°C
      • Working Humidity: 20%–80%
      • Dimensions: 150mmX150mmX167.5mm
      • Weight: 1.4KG
      • Working Environment: Indoor
      • Remote Operation (IP): Remote Upgrade, Reboot, and Reset

    • Item Includes:

      • 1x Power Supply
      • 1x RS232 Control Cable?USB Cable
      • 1x Remote Control
      • 1x Manual
      • 1x Warranty card
      • 1x Wall Mount

    • Warranty:

      • 7 years

    • GTIN:

      0781159724879
