Appsys ProAudio FLX-MADI/SRC-SFP 2-Port Optical MADI-to-Anything Converter with Built-In 64x64ch Sample Rate Converter

FLX-MADI/SRC-SFP - Overview

MADI optical to anything. Anything to MADI optical. Including Sample Rate Conversion!

• Features:

  • Two MADI SFP ports, accepting ANY brand of SFP
  • Built-in wordclock IN/OUT
  • AUX port accepting any of the AUX Cards as conversion source/destination
  • When combined with AUX-MADI-COAX-DUAL or AUX-MADI-SFP-DUAL, it acts as MADI/MADI bridge with full network and clock domain separation, for up to 64x64ch at 96kHz. Other targets (e.g. DANTE) can be realized with the appropriate AUX card
  • 64x64ch bi-directional Sample Rate Converter with top-notch specifications (>120dB THD+N, >134dB DNR), can be bypassed when desired
  • Supports sample rates from 44.1kHz to 192kHz on either side
  • FlexLink port for lowest latency, bi-directional transfer of 192 channels audio, clock and power
  • Remote control via USB: Web remote (no software required), or UART command line
  • Triple-redundant power supply
    *Additional features when connected to the MVR-mkII: True channel-wise routing of all available channels (built-in plus AUX card)


• Specifications:

  • Dimensions: 3.50" x 8.00" x 6.60"
  • Weight: 2lbs


• Item Includes:

  • 1x Appsys ProAudio FLX-MADI/SRC-SFP 2-Port Optical MADI-to-Anything Converter with Built-in 64x64ch Sample Rate Converter


• GTIN:

  0070061361811
