    SW-C6IRLT-R - Overview

    The SW-C6IRLT-R HDBaseT™ Lite HDMI over Single CAT5e/6/7 Extender incorporating 2-way IR signal transfer allows for a more efficient system setup and is easy to install. Uncompressed video and audio can be transmitted to distances of up to 60 meters (1080p) or up to 35 meters (4Kx2K) and supports High Definition Audio and 3D signals. Designed with HDBaseT Lite technology for greater flexibility in custom installations with full HDMI and 2-way IR control signal transfer over a single CAT5e/6/7 cable.

    Please Note: When displaying a 3D signal with a higher bandwidth than 225 MHz or a 4Kx2K resolution source, a High Speed HDMI cable is required.

    • Features:

      • HDMI including 3D and 4Kx2K (Ultra HD) support, HDCP and DVI compliant
      • Supports HDCP repeater and CEC bypass
      • Supports HDBaseT Lite Technology including 2-Way IR and RS-232
      • Supports transmission distance of up to 60 meters through CAT5e/6/7 cable (1080p or 3D) or 35 meters (4Kx2K)
      • Supports HDMI input up to 15 meters at 8-bit resolution or 10 meters at 12-bit resolution and output up to 15 meters at 8-bit or 12-bit resolution
      • Audio support up to LPCM 7.1CH, Dolby TrueHD, Dolby Digital Plus and DTS-HD Master Audio
      • Compact size with stylish design
    • Specifications:

      • Video Bandwidth: 300 MHz/10.2 Gbps
      • HDCP and DVI: Compliant
      • Data Rate: 5.3 Gbps
      • HDMI Supported Resolutions: 480i @ 60Hz, 480p @ 60Hz, 576i @ 50Hz, 576p @ 50Hz, 720p @ 50/60Hz/3D, 1080i @ 50/60Hz,1080p @ 24Hz / 50/60Hz/3D, ulTRA HD (3840x2160)@24Hz 4k x 2k @ 24Hz
      • Input: 1xCAT5e/6/7, 1xIR Extender
      • Output: 1xHDMI, 1xIR Blaster
      • HDMI Cable: 4k2k: ([email protected]) ~ 35meter (115 feet); full HD: (1080p) ~ 60meter (197 feet)
      • Audio Support: LPCM 7.1CH, Dolby TrueHD, Dolby Digital Plus and DTS-HD Master Audio
      • Dimensions (L x W x H): 2.2" x 3.2" x 0.88"
      • Weight: 0.14 lbs
      • Power Supply: 5 V/2.6 A DC (US/EU standards, CE/FCC/UL certified)
      • Power Consumption: 5.5 W
      • Operating Temperature: 32° ~ 104°F (0° to 40°C)
      • Storage Temperature: -4° ~ 140°F (-20° ~ 60°C)
      • Relative Humidity: 20~90% RH (no condensation)
    • Warranty:

      • 3 Year
    • GTIN:
