Belden 6102UE 14 AWG 4 Conductor Plenum-CL2P Cable - 1000 Foot Spool

ITEM #: BL-6102UE-1000 MFG #: 6102UE 8771000

Primary Image
  • Product Image Thumbnail 1 of 3
  • Product Image Thumbnail 2 of 3
  • Product Image Thumbnail 3 of 3
Belden
Free Shipping with $49 Minimum Order

Item unavailable. Please select another option.

Ask a Markertek Expert if you need assistance finding an appropriate substitute.

List Price:

$998.70

Our Price:

$803.70

Add to Wish ListLeasing Options
Availability: Usually Ships in 5-14 Days.
Please Email, Chat or Call (800) 522-2025 for Detailed Delivery Info
iAvailability Description Popup
Report Lower PriceLarge Quantity Quote

6102UE 8771000 - Overview

Belden 6102UE is a Security & Sound Cable with Plenum-CL2P 4-14 AWG stranded bare copper conductors with Flamarrest® insulation and Flamarrest® jacket with ripcord. Suitable for Security System, Intercom/PA, Audio/Speaker, Power-Limited Controls applications.

  • Specifications:

    • AWG: 14
    • Stranding: 19x27
    • Material: BC - Bare Copper
    • Conductor Count: 4
    • Material: No Shield
    • Nominal Conductor DCR: 2.53 Ohm/1000ft
    • Nom. Capacitance Conductor to Conductor: 37 pF/ft
    • Nominal Inductance: 0.15 µH/ft
    • Max. Recommended Current [A]: 6.4 Amps per conductor @ 25°C A
    • UL Voltage Rating: 150 V RMS
    • Operating Temp Range: 0°C To +75°C
    • Bulk Cable Weight: 69.1 lbs/1000ft
    • Max Recommended Pulling Tension: 190 lbs
    • Min Bend Radius/Minor Axis: 2.5 in
    • CEC/C(UL) Specification: CMP
    • CPR Euroclass: Eca


  • GTIN:

    0612825173595
