Belden 7787A 3 Channel SDI Coaxial Cable - Per Foot

7787A PER FOOT - Overview

• Features:

  • Bundled Number of Coax: 3
    RG Type: Mini
    AWG: 23
    Stranding: solid
    Conductor Material: BC - Bare Copper
    Insulation Material: Gas-injected FHDPE - Foam High Density Polyethylene
    Inner Shield Material: Aluminum Foil-Polyester Tape-Aluminum Foil/TC - Tinned Copper
    Inner Jacket Material: PVC - Polyvinyl Chloride
    Outer Shield Material: Unshielded
    Outer Jacket Material: PVC - Polyvinyl Chloride
    Plenum (Y/N): N
    Nom. Characteristic Impedance: 75 +/- 3O


• GTIN:

  0612825357964
