Belden C6T1100002 Cat6+ Traceable Patch Cord - Black - 2 Foot

ITEM #: BL-C6T1100002 MFG #: C6T1100002

Primary Image
Belden
Free Shipping with $49 Minimum Order

List Price:

$15.22

Our Price:

$12.62

Add to Wish ListLeasing Options
Availability: Typically Ships in 3-10 Business Days
iAvailability Description Popup
    Report Lower PriceLarge Quantity Quote

    C6T1100002 - Overview

    Belden C6T1100002 is a Cat6+ Traceable Patch Cord. It is suitable for IBDN System 4800, 3600 and 2400, TIA Category 6, ISO Class E, 1000BASE-T, 20 and 40 sec. flashing high intensity LED Battery operated (included), push button activated.

    • Specifications:

      • Total Number of Pairs: 4
      • Overall Nominal Diameter: 0.238 in
      • Wiring Scheme: T568A/B-T568A/B
      • Packaging: Individually packaged in a clear plastic bag
      • Boot: Elastomer Translucent
      • Conductor: BC - Bare Copper
      • Front Connection: Blades Phosphor Bronze with 50u inch Gold over Nickel Plating
      • Inner Jacket: PVC - Polyvinyl Chloride
      • Insulation: PO - Polyolefin
      • Outer Jacket: PVC - Polyvinyl Chloride
      • Current Rating: 1.500 A
      • Insulation Resistance: 500 M-Ohm Minimum
      • Max Contact Resistance: 20 mOhm
      • Installation Temperature Range: -10°C To +60°C
      • Storage Temperature Range: -40°C To +70°C
      • Operating Temperature Range: -20°C To +75°C
      • Min Bend Radius (Overall Cable): 1.040 in
      • Plug /Jack Compatibility: RJ45
      • UL Rating: Riser
      • Environmental Space: Riser


    • Item Includes:

      • 1x Belden C6T1100002 Cat6+ Traceable Patch Cord - Black - 2 Foot
