    HD-PRO - Overview

    All ChyTV systems come standard with software, one year warranty and Lifetime Product phone and E-mail support. There are no license fee's!

    Live HD-SDI In and Out with Squeeze and Overlay
    The ChyTV HD Pro is an affordable professional broadcast television graphic system, supporting HD-SDI and analog HD In and Out. With the HD Pro, you can take in virtually any flavor of live HD input and squeeze and position it within your content uniquely from page to page. Or overlay graphics on top of the full screen video. All without compromising your closed captioning information. This is truly a broadcast quality professional product. Like all ChyTV products, the HD Pro gives you full control over each element on the page. You can have a full motion HD clip as a background with layered graphics, text and animations on top, along with a live HD video window of any size and position, or a variety of other arrangements. ChyTV HD Pro utilizes the same ChyTV Tools utilities to manage the projects and is completely compatible with existing ChyTV units. Like all ChyTV products, the HD Pro features the highest quality dynamic text and effects, even in Portrait display mode.

    Text and Graphics Image Engine
    The HD Pro is ideal For PEG Channels (Public, Education, Government). Some of the many Public Access Channel uses include: Local community announcements, Local weather, Community advertising, Town meeting announcements, agendas and minutes, Public Service announcements, and Emergency Alerts The ChyTV HD Pro features an internal MPEG clip player and has the ability to manipulate the video clip either in a window that is surrounded by graphics and text or to superimpose the message over the video background. In addition, full screen graphics can be displayed with dynamic text, logos and animations. A versatile play-list scheduler allows for dynamic programming. The supplied ChyTV Tools user interface allows for direct control of the ChyTV HD Pro, or multiple ChyTV HD Pro's can be added to the server for automatic remote content updates.

    Flexible and Reliable
    The ChyTV system is easy to configure in a display system or integrated into an existing HD video infrastructure. Standard format animations can be imported from various file types such as MPEG clips, GIF, AVI, TGA sequences, etc. All graphic pages can then be scheduled from a simple, intuitive scheduling interface for either automatic looping or date/time playout. This self-contained device is virtually virus-proof, requires no external computer connection and ensures utmost reliability and ease of use.

    • Features:

      • Supports HD-SDI In and Out with Closed Captioning as well as Embedded audio.
      • Live HD Input, both windowed or full-screen overlaid. Various HD video formats.
      • Layered page elements include live video, clips, text, graphics and backgrounds
      • Full-screen HD clips as animated backgrounds overlaid with dynamic text and graphics.
      • Dynamic real-time 3D Text and Graphics
      • Squeeze and position live video and clip player windows, including dynamic transitions
      • Dynamic broadcast quality effects such as text pushes, fades and crawls
      • Animated Text, Graphics and Logos using GIF, TGA, MPEG and more
      • Multiple text and graphic zones may be independently sized and positioned
      • Page scheduling, including looping duration or specific day, date and time control
      • External data interfaces for realtime data updates such as news, sports, stock and weather
      • Interfaces with a variety of peripheral devices including RFID, touch screen, contact closure switches, serial control and more.
    • Specifications:

      • Video Outputs
      • Outputs may not be available simultaneously
      • Digital:
        HD HDMI
        HD/SD SDI (BNC)
        Internal / External SDI Key Channel
      • Analog: HD/SD Composite, Component via Breakout Cable

        Video Inputs
      • Digital:
        HD HDMI
        HD/SD SDI (BNC)
      • Analog:
        HD/SD Composite, Component via Breakout Cable
        Video Formats: 525, 625, 720p, 1080i

        Audio Outputs
      • Number of Outputs: 5
        1x HDMI In
        1x Line-out
        1x Embedded SDI
        2x Channel Balanced Analog and AES / EBU via Breakout Cable
      • Number of Inputs: 5
        1x HDMI In
        1x Line-in
        1x Embedded SDI
        2x Channel Balanced Analog and AES / EBU via Breakout Cable

      • USB: USB 2.0, 3.0
      • Ethernet: 10/100/1000 BaseT (RJ-45)

        Rack Chassis
      • Weight: 43Lbs
      • Dimensions (HxWxD): 5 x 16 x 16.5" (127 x 406 x 419mm)
      • Power Supply: 80 PLUS EPS-12V 550W Mini Redundant Power Supply
    • Warranty:

      • 1 Year Warranty
