CNDLive D1 8-channel 4K HDMI & 3G-SDI Video Decoder - Supports H.265/H.264 and NDI

Name: CNDLive D1 8-channel 4K HDMI & 3G-SDI Video Decoder - Supports H.265/H.264 and NDI
Brand: CNDLive
SKU: CND-D1
Price: 549.00 USD
Availability: Backorder

ITEM #: CND-D1 MFG #: D1

CNDLive

Our Price:

$549.00

Add to Wish List Leasing Options

Availability: Usually Ships in 5-14 Days.
Please Email, Chat or Call (800) 522-2025 for Detailed Delivery Info

Notify when in stock

Report Lower Price Large Quantity Quote

Required Accessories

Recommended Accessories

D1 - Overview

If Encoders are Designed to Push your Content to the World, the D1 Decoder is Designed to Pull it Back.

The CNDLive D1 is an advanced and professional video decoder,equipped with HDMI2.0 and 3GSDI dual outputs, capable of dealing with multiple video formats and coding standard.

One Unit for Multiple Needs
D1 supports full protocols in the market, including NDI HB, NDI HX2/3, SRT, RTSP, RTMP, RTMPS, HLS, TS over UDP, meeting diverse market demands and ensuring seamless integration and decoding for various workflows.

Dual Interfaces Flexible Output Selection
D1 offers users the flexibility to select between 3G-SDI and 4K HDMI output interfaces,enabling them to synchronize the display of same or different video sources according to the real scene.

Easy to Use and Set Up
Equipped with a built-in 2 LCD screen for easy configuration and preview in realime, to effortlessly check the working status, monitor network conditions and access other data at a glance.

Powerful and Professional Decoding Capability
Enriching Your Experience Interlaced and B-frame sources decoding on both device and Web-side, 4 channels preview.

Features:
- Multiple-Audio Decoding and Rich Audio Formats: D1 supports standards such as AAC, MP3, MP2, MPA, G.711, Opus, LPCM and SDI/HDMI 8 channels audio decoding
- RTMP Server Supported: With the RTMP server, D1 can connect directly from the video encoder like our C6 or other devices and output the stream via RTMP without any relay platform, thus simplifying your workflow
- H.264/H.265: Supports decoding 2 channels of 4Kp60 or 8 channels of 1080p60
- Supports interlaced signal decoding, offering better compatibility with traditional video sources
- Legacy Support: Capable of decoding interlaced signals to better support traditional video sources
- Expansion: Includes USB 3.0 and Type-C ports
- Overlay: Supports text and image overlay on the decoded output
Specifications:
- Video Interfaces:
  - 1x 3G-SDI (SMPTE 424M / HD-SDI / SD-SDI)
  - 1x HDMI 2.0
- Decode Output (SDI):
  - 1080p: 60, 59.94, 50, 30, 29.97, 25, 24, 23.98
  - 1080i: 60, 59.94, 50
  - 720p: 60, 59.94, 50
- Decode Output (HDMI):
  - 4K: 60, 50, 30, 25, 24
  - 1080p: 60, 59.94, 50, 30, 29.97, 25, 24, 23.98
  - 1080i: 60, 59.94, 50
  - 720p/SD: 60, 59.94, 50, 576p50, 480p60
- Decoding Protocols: NDIHB, NDIHX2/3, SRT, RTMP, RTMPS, HLS, TS over UDP, RTSP, RTMP Server
- Decoding Capacity:
  - NDIHB: 1x 4Kp60 or 4x 1080p60
  - H.264/H.265: 2x 4Kp60 or 8x 1080p60
- Audio Interface: 1x 3.5mm Line Out
- Audio Decoding:
  - AAC
  - MP3
  - MP2
  - MPA
  - G.711
  - Opus
  - LPCM; SDI/HDMI 8-Channel support
- Network: 2x 10/100/1000M Ethernet (1x PoE supported)
- Peripherals: 1x USB-A 3.0; 1x Type-C
- Display: 2.0" LCD screen and control buttons
- Management: Web-based Management; Centralized Management Platform
- Power: DC 12V/2A; Consumption ≤ 9W
- Dimensions(L x W x H): 5.51" x 5.19" x 1.77" (140mm x 132mm x 45mm)
- Working Temperature: 14°F - 113°F (-10°C - 45°C)
Item Includes:
- 1x D1 Host Unit
- 1x Power Adapter
- 1x Warranty Card
- 1x Quick Start Guide
- 1x Quality Certificate
