Elation Professional ESM166 Smarty Max Extreme Output Hybrid DJ Lighting

ITEM #: ELAT-ESM166 MFG #: ESM166

Primary Image
  • Product Image Thumbnail 1 of 5
  • Product Image Thumbnail 2 of 5
  • Product Image Thumbnail 3 of 5
  • Product Image Thumbnail 4 of 5
  • Product Image Thumbnail 5 of 5
Free Shipping with $49 Minimum Order

List Price:

$8,500.00

Our Price:

$6,800.00

Availability: Ships Factory Direct, Typically in 3-10 Business Days
iAvailability Description Popup
  • Shipped truck freight.


ESM166 - Overview

The SMARTY MAX™ combines high output and long lamp life in a feature packed compact and lightweight Hybrid fixture. SMARTY MAX is the Extreme Output Hybrid featuring the new Philips MSD Platinum FLEX 400 lamp and Elation's 2 year / 4,000 hours Ultimate Warranty. Rated at 480W and up to 4,000 hours smart lamp life the SMARTY MAX includes CMY and variable CTO and is the world’s first Hybrid incorporating a full Iris for dynamic beam effects. Four prisms on two planes, dual frosts plus dual gobo wheel and the unique dual track animation round out the comprehensive FX package in a compact and lightweight housing. Delivering 21,000 lumens from its large 160mm front aperture, the SMARTY MAX has a crisp output for extremely powerful beams, sharp gobos and bright washes, making it a flexible fixture for almost any application, while providing an excellent return on investment.

  • Features:

    • Extreme Output 3-in-1 Beam, Spot, Wash Hybrid Fixture
    • Flex Lamp Technology from 370 to 480W plus Smart Hibernation with up to 4,000 Hour Lamp Life
    • Full CMY Color Mixing System, Variable CTO, Color Wheel
    • Creative FX Package: 8 Rotating and 15 Static Gobos, Dual Track Animation, Iris 4x Prism on Dual Planes, 2x Frost
    • Ultra-Fast Zoom: Beam 1.5° - 6° | Spot 3° - 26.5° | Wash 12° - 39°

  • Specifications:

    • Source:
    • Philips MSD Platinum 400 Flex 480W Lamp
    • Variable Lamp Power 370/470/480W
    • Automated Lamp Hibernation with Instant Recovery
    • Up to 4,000 Hour Lamp Life*
    • *Test lab conditions. May vary depending on several factors including but not limited to:
    • Environmental Conditions, Power/Voltage, Usage Patterns (On-Off Cycling),Control, and Dimming.

      Photometric Data:
    • 21,000+ Lumen Total Fixture Output
    • 1.5° Beam: 1,784,448 LUX (165,781 FC) @5m (16.4ft)
    • 3° Spot: 462,508 LUX (42,968 FC) @5m (16.4ft)

      Effects:
    • Beam, Spot and Wash Modes
    • Motorized Zoom 1.5° Beam to 39° Wash
    • Dual Frost Filter for Light Frost/ Full Wash
    • 4 Prisms on Dual Planes
    • Iris
    • CMY Color, Gobo, Prism Macros
    • Motorized Focus with Auto-Focus Feature
    • High Speed Shutter and Strobe

      Color:
    • Full CMY Color Mixing System
    • Variable CTO
    • 13 Position Color Wheel

      Gobos:
    • 2 Gobo Wheels
    • 8 Interchangeable-Rotating / Indexing Glass Gobos
    • 14 Static-Stamped Metal Gobos
    • Dual Track Animation Wheel

      Control / Connections:
    • 2 DMX Channel Modes (27 / 44 Channels)
    • (6) Button Touch Panel
    • Full Color 180° Reversible LCD Menu Display
    • DMX, RDM, Art-Net and sACN Protocol Support
    • 5pin DMX In/Out
    • RJ45 Ethernet In/Out
    • IP65 Locking Power Cable In/Out
    • With Wired Digital Communication Network

      Size / Weight:
    • Length: 15.34” (389.8mm)
    • Width: 17.53” (445.3mm)
    • Height: 25.27” (642mm)
    • Weight: 60.0 lbs. (27.2kg)

      Electrical / Thermal:
    • AC 100-240V 50/60Hz
    • 700 W Max Power Consumption (estimated)
    • 14°F to 113°F (-10°C to 45°C)
    • BTU/hr (+/- 10%) 2387

      Approvals / Ratings:
    • CE
    • cETLus
    • IP20

  • Item Includes:

    • 1x ESM166 Extreme Output Hybrid DJ Lighting
    • 1x Power Cable

  • Warranty:

    • 2 Year

  • GTIN:

    0810008260166
