Ivory Cat5 Wall Plate with BNC Video and Stereo RCA Audio

ITEM #: ETS-AV900WPIY MFG #: AV900WPIY

free ship

Item unavailable. Please select another option.

Ask a Markertek Expert if you need assistance finding an appropriate substitute.

List Price:

$95.50

Our Price:

$81.86

Availability: Typically Ships in 3-10 Days
iAvailability Description Popup


    AV900WPIY - Overview

    The ETS AV900WP, AV901WP and AV906WP have been redesigned with new flat circuit boards providing Baseband Video/Stereo Wall Plates which are utilized for point-to-point replacement of coaxial (video) and shielded (high impedance audio) cables with UTP wiring, Category 5 or better.

    The AV901WP (with 3 RCA jacks for all inputs) is designed for installations that have a need for separate audio channels. For example, some VCRs and Video Cameras have video plus stereo outputs available on three RCA jacks. The AV901WP can run these signals using three of the four pairs in standard UTP cable.

    AV906WP (with 4 RCA jacks for all inputs) allows you to send two channels each of baseband video and audio in any direction desired. This capability yields, for instance, a bi-directional video + mono audio link, or many other configurations.

    You get the same high quality baluns with the addition of an enhanced appearance of wall plates, giving you a neater professional installation.

    • Features:

      • Decorator balun wall plates for a sleeker, cleaner professional installation
      • Easy installation with punch down blocks
      • Ports are pre-labeled and easily identified
      • 1 or 2 baseband video channel and 2 line level audio channels on one run of Category 5 UTP
      • Use for point to point replacement of coax and shielded cables
      • Available in WHITE or IVORY
      • Made in USA. 100% tested

    • Specifications:

      • Bandwidth Flat to 60 MHz (video) 10Hz to 20kHz (audio)
      • Connectors FBNC or RCA jackjacks (audio) to 110type
      • Common Mode Rejection >50dB (video)
      • Impedance 600:600 (audio)
      • Isolation 500 V (audio, per channel)
      • Dimensions 79mm x 123mm x 40mm
      • Net Weight 0.08 kg
