Gra-Vue MMIO EMB-HDSDI 3G/HD/SD-SDI Dual Analog Audio Embedder

ITEM #: GFE-MMIOEMBHDSDI MFG #: MMIO EMB-HDSDI

  • Product Image Thumbnail 1 of 4
  • Product Image Thumbnail 2 of 4
  • Product Image Thumbnail 3 of 4
  • Product Image Thumbnail 4 of 4
free ship

List Price:

$439.95

Our Price:

$419.95

Availability: Direct Ship from manufacturer, contact us for availability
iAvailability Description Popup
  • Special Order Item: non-cancelable, non-returnable, non-refundable.


MMIO EMB-HDSDI - Overview

The MMIO EMB-HDSDI is a miniature 3Gb/s HDTV/SDI balanced Analogue audio embedder which embeds one balanced stereo signal into the ancillary data space of a 3Gb/s, 1.485Gb/s or 270Mb/s SDI signal. The input stream is embedded as 24 bit audio. Embedding conforms to SMPTE 272M and allows audio to be inserted into any of the four groups, selectable via dip switches. There is automatic input cable equalisation to 50m and a re-clocked SDI output. The unit is housed in an extremely compact and rugged aluminium case and is suitable for both field and studio applications.

MMIO EMB-HDSDI - Required Accessories
