KanexPro AUD-DTE-LINEOUT Dante 2-Channel Line Output Adapter with 5-Level Gain Adjustment - PoE & USB-C Powered

AUD-DTE-LINEOUT - Overview

Convert Dante digital audio to balanced or unbalanced analog line output with studio-grade fidelity!

• Features:

  • Dante 2-Channel digital audio to two-channel balanced/unbalanced analog audio output
  • Built on the Dante Ultimo 2x2 platform for full Dante ecosystem interoperability
  • Supports 44.1/48/88.2/96kHz sampling rates at 24-bit resolution
  • 5-level discrete gain adjustment (+18dBu, +4dBu, 0dBu, 0dBV, -10dBV)
  • Balanced Output: +18dBu max/Unbalanced: +12dBu max
  • Studio-Grade Audio: >100dB S/N ratio, <0.01% THD+N
  • Configurable Dante Device Latency: 1ms, 2ms, or 5ms
  • Dual Power: PoE (IEEE 802.3af Class 0) and USB-C (5V/500mA)
  • 6-pin 3.5mm phoenix connector for permanent installation


• Specifications:

  Technical
  • Input: Dante 2-channel digital audio
  • Output: 2-channel balanced/unbalanced analog
  • Sampling: 44.1/48/88.2/96kHz @24bit
  • S/N Ratio: >100dB
  • THD+N: <0.01%
  • Gain: 5-level: +18dBu, +4dBu, 0dBu, 0dBV, -10dBV
  • Latency: 1ms/2ms/5ms configurable
  • Network: 100m CAT6

    Connections
  • Input: 1x DANTE RJ45 (PoE)
  • Output: 2x LINE OUT (phoenix)
  • Power: USB-C 5V/500mA

    Mechanical
  • Power: 1.25W max
  • Dimensions (WxDxH): 4.53" x 1.57" x 1.10" (115mm x 40mm x 28mm)
  • Weight: 0.21lbs (94g)


• Item Includes:

  • 1x Dante 2CH Line Output Adapter
  • 1x 6-pin 3.5mm Phoenix Connector (male)
  • 2x Hook & Loop
  • 1x User Manual
