KanexPro KVM-2X1HDMI8K 2x1 HDMI 8K@60 KVM Switcher with Hotkey Switching - 2x Host with USB 3.0 to 1x HDMI Output

KVM-2X1HDMI8K - Overview

• Features:

  • HDCP 2.3 compliant
  • Supports Ultra-wide Screen, resolution up to 8K@60Hz, 4K@120Hz/144Hz, 1080P@240Hz
  • Supports VRR, ALLM, QMS, QFT, SBTM as specified in HDMI 2.1
  • HDR, HDR10, HDR10+, Dolby Vision, HLG pass-through
  • Using only 1 set of keyboard, mouse and monitor to control 2 computers
  • Support video fast switching, and keyboard/mouse seamless switching
  • Each input port has an EDID emulator to provide the correct informationfor the PC
  • Supports hot plug, disconnect or connect devices to the KVM at any time
  • Switching via front panel buttons, keyboard/mouse hotkeys, IR remote control, and RS-232 commands
  • Supports auto switching
  • Advanced hardware/software design and production ensure zero latency
  • The integrated USB 3.0 ports allow you to share USB peripherals like printer, scanner, webcam and hard disk between computers with data transfer rate up to 5Gbp/s
  • Compact design for easy and flexible installation


• Specifications:

  Technical
  • HDMI Compliance: HDMI 2.1
  • HDCP Compliance: HDCP 2.3
  • Video Bandwidth: 40Gbps
  • Video Resolution: Up to 8K @ 60Hz, 4K @ 120Hz/144Hz, 1080P @ 240Hz
  • IR Level: 5Vp-p
  • IR Frequency: Fixed frequency 38KHz
  • Audio Latency: No latency
  • Video Latency: No latency
  • Color Space: RGB_4:4:4, YCbCr_4:4:4, YCbCr_4:2:2, YCbCr_4:2:0
  • Color Depth: 8/10/12bit
  • HDR: HDR10, HDR10+, Dolby Vision, HLG
  • Audio Format: HDMI IN/OUT: LPCM, DolbyDigital/Plus/EX, DolbyTrueHD, DolbyAtmos,DTS ,DSD ,DTS-EX, DTS-96/24, DTS High Res, DTS-HD Master Audio, DTS:X, DSD
  • L/ROUT: PCM 2.0CH
  • ESD Protection: IEC 6100-4-2: 8kV (Air-gap discharge) , ±4kV (Contact discharge)

    Connections
  • Input Ports: 2x HDMI input[HDMI Type A , 19-pin female]
  • Output Ports:
    - 1x HDMI output[HDMI Type A, 19-pin female]
    - 1x L/R audio output [3.5mm Stereo Mini-jack]
  • Control Ports:
    - 1x RS-232 [3pin-3.81mm phoenix connector]
    - 1x IR EXT [3.5mm Stereo Mini-jack]
    - 2x USB HOST [USB Type B]
    - 4x USB DEVICES [USB Type A]

    Mechanical
  • Housing: Metal enclosure
  • Color: Black
  • Dimensions: 6.88" x 4.17" x 0.6" (175mm x 100mm x 30mm)
  • Weight: 3.81lbs (626g)
  • Power Supply:
    - Input: AC 100V - 240V 50/60Hz
    - Output: DC 12V/1A (US/EU standards, CE/FCC/UL certified)
  • Power Consumption:
    - Typical: 5.18W
    - Standby: 0.6W
  • Operating Temperature: 32°F - 104°F (0°C - 40°C)
  • Storage Temperature: -4°F - 140°F (-20°C - 60°C)
  • Relative Humidity: 20% - 90% RH (non-condensing)

    Recommended HDMI Cable - Resolution/Cable Length
  • HDMI IN/OUT:
    - 8K60/8K30/4K120 6.6ft (2m)(Ultra HDMI 2.1 cable)
    - 4K60 16ft (5m)(HDMI cable)
    - 1080P 33ft (10m)(HDMI cable)
    *The use of "Premium High Speed HDMI" cable is highly recommended.


• Item Includes:

  • 1x 8K60 2x1 KVM Switcher
  • 1x IR Remote
  • 1x 3pin-3.81mm Phoenix Connector (male)
  • 1x Fixed Frequency 38KHz IR Receiver Cable (1.5 meters)
  • 2x USB Cable (USB 3.0, AM to BM, 1.8 meters)
  • 2x HDMI Cable (male to male, 1.5 meters)
  • 2x Mounting Ears
  • 4x Machine Screws (KM3*4)
  • 1x 12V/1A Multinational Locking Power Supply
  • 1x User Manual


• GTIN:

  0813982023581
