Kramer FC-332 3G HD-SDI to HDMI (Dual Output) Format Converter

FC-332 - Overview

3G HD-SDI to HDMI Format Converter

• Features:

  • HDTV Compatible
  • Looping Input
  • Multi-Standard Operation - SDI (SMPTE 259M), HD-SDI (SMPTE 292M) and 3G HD-SDI (SMPTE 424M) compliance and support for data rates of 270Mbps, 1483.5Mbps, 1485Mbps and 2970Mbps.
  • Embedded Audio Group Select Rotary Switch
  • Active Input Indication™ Reporting - Green indicates a standard definition (SDI) input signal and blue indicates a high definition (HD-SDI) input signal
  • Compact DigiTOOLS™ - 3 units can be rack mounted side-by-side in a 1U rack space with the recommended rack adapter


• Specifications:

  • Input: 1 SD/HD/3G HD-SDI with loop on BNC connectors
  • Outputs: 2 HDMI connectors
  • Max. Data Rate: Up to 3Gbps
  • Standard Compliance: HDMI
  • Indicator LEDS: SD/HD, OUT, ON
  • Power Consumption: 5V DC, 510mA
  • Product Dimension: 12 x 7.15 x 2.44cm (4.72 x 2.81 x 0.96")
  • Product Weight: 0.7lbs (0.3kg) approx.
  • Shipping Dimension: 9.13 x 4.72 x 3.50" (23.20 x 12 x 8.90cm)
  • Shipping Weight: 1.3lbs (0.6kg) approx.


• Item Includes:

  • 1x FC-332 Converter
  • 1x Power Supply


• GTIN:

  7291063030513
