Kramer VM-24HC 2x1:4 Compact HDMI Switchable DA

VM-24HC - Overview

HDTV Compatible & HDCP Compliant

• Features:

  • Max. Data Rate - 6.75Gbps (2.25Gbps per graphics channel).
  • HDTV Compatible.
  • HDCP Compliant.
  • EDID Pass-through - Pass-through algorithm ensures Plug and Play operation for HDMI source and display systems.
  • EDID Handling - Acquires the EDID from one output, from all connected outputs (auto-mix) or uses a default EDID.
  • Kramer Equalization & re-Klocking™ Technology - Rebuilds the digital signal to travel longer distances.
  • HDMI Support - With Deep Color, x.v.Color™, up to 7.1 Uncompressed Audio Channels.
  • 3D Pass-Through.
  • Flexible Control Options - Front panel, IR remote & RS-232.
  • Desktop Size - Compact size. 2 units can be rack mounted side-by-side in a 1U rack space with the recommended rack adapter.


• Specifications:

  • INPUTS
  • 2 HDMI connectors


  • OUTPUTS
  • 4 HDMI connectors


  • MAX. DATA RATE
  • 6.75Gbps (2.25Gbps per graphic channel)


  • COMPLIANCE WITH HDMI STANDARD
  • Supports HDMI and HDCP


  • CONTROLS
  • EDID SELECT, EDID READ, IN 1, IN 2 buttons, RS-232, IR


  • INDICATORS
  • POWER, IR, OUTPUT LEDs


  • POWER CONSUMPTION
  • 5V DC, 1.1A


  • OPERATING TEMPERATURE
  • 0° to +40°C (32° to 104°F)


  • STORAGE TEMPERATURE
  • -40° to +70°C (-40° to 158°F)


  • HUMIDITY
  • 10% to 90%, RHL non-condensingr.


• Item Includes:

  • VM-24HC DA
  • Power Supply


• Warranty:

  • Limited 7 Year Warranty


• GTIN:

  7291063000622
