Kramer VS-88HDCPXL 8x8 DVI (HDCP) Matrix Switcher

VS-88HDCPXL/110V - Overview

• Features:

  • Max. Data Rate - 6.75Gbps (2.25Gbps per graphic channel).
  • HDCP Compatible.
  • HDTV Compatible.
  • HDMI Support - Deep Color, x.v.Color™, 3D Pass-Through, HDMI Compressed Audio Channels.
  • EDID Capture - Copies and stores the EDID from a display device.
  • Output Disconnect - Each output.
  • Front Panel Control Lockout.
  • Memory Locations - Stores multiple switches as presets to be recalled and executed when needed.
  • Flexible Control Options - Front panel, IR remote, RS-232 (K-Router™ Windows®-based software is included), Ethernet (Windows®-based Ethernet Configuration Manager & Virtual Serial Port Manager is included).
  • Worldwide Power Supply - 100-240V AC.


• Specifications:

  • INPUTS
  • 8 DVI-D connectors


  • OUTPUTS
  • 8 DVI-D connectors


  • BANDWIDTH
  • 6.75Gbps (2.25Gbps per graphic channel)


  • COMPLIANCE WITH HDMI STANDARD
  • Supports DVI and HDCP


  • RESOLUTION
  • Up to UXGA
  • 1080p


  • POWER CONSUMPTION
  • 100-240V AC, 50/60Hz, 40VA


  • CONTROLS
  • Front panel buttons, infrared remote control transmitter, RS-232, Ethernet


  • OPERATING TEMPERATURE
  • 0° to +40°C (32° to 104°F)


  • STORAGE TEMPERATURE
  • -40° to +70°C (-40° to 158°F)


  • HUMIDITY
  • 10% to 90%, RHL non-condensing


• Item Includes:

  • VS-88HDCPXL Switcher
  • Power Cord
  • IR Transmitter
  • Rack Ears (1 set)
  • Rubber Feet (4)


• Warranty:

  • Limited 7 Year Warranty


• GTIN:

  7291063003517
