    GSW-1657 - Overview

    Gigabit Speeds: Take Your Data to the Next Level
    The LevelOne GSW-1657 is a 16-port Gigabit Ethernet Switch that gives you a high-performance, low-cost, easy-to-use, seamless upgrade to boost your network to 1000Mbps. Increase the speed of your network backbone to a massive 32Gbps and bring Gigabit speeds all the way to your computers.

    Bandwidth hungry? Not a problem.
    What happens when you have several users accessing multimedia applications all at the same time? No need to worry as GSW-1657 allows you to move large files faster and easier. Transfer your CGI, CAD, video, or other large multimedia files over the network instantly and without lag.

    Plug and Play, Flexible and Easy
    GSW-1657 is plug-and-play so no configuration is required. Providing auto MDI/MDI-X cable detection on all ports eliminates the need for crossover cables or Uplink ports. Each port can be used as general ports or Uplink ports, and any port can be simply plugged into a server, a hub, a router or a switch, using a straight cable or crossover cable. Diagnostic LEDs which display link status and activity, allowing you to quickly detect and correct problems on the network.

    • Features:

      • 16 Gigabit Ethernet ports
      • 10/100/1000Mbps wire speed transmission and reception
      • Supports 8K MAC address auto-learning and auto-aging
      • 9K jumbo frames to increase data transfer rates
      • Minimize carbon footprint with advanced energy efficient technology (IEEE 802.3az)
      • 19-inch metal housing

    • Specifications:

      • Standards:
        IEEE802.3(10BASE-T)
        IEEE802.3u(100BASE-T)
        IEEE802.3ab(1000BASE-T)
        IEEE802.3az Energy Efficient Ethernet
      • Memory: 64Kbit
      • Buffer Memory: 2Mbit
      • Port: Full Shielded
      • Indicator: Power
      • LINK/ACT: 1000M loop detection
      • Transmission Method: Store- froward
      • Power Input: AC100-240V
      • Power Output: 12V/2A
      • Power Consumption: 15W
      • Backplane (Gbps): 32Gbps
      • MAC Address Table: 8K
      • Power Saving: IEEE802.3az Energy Efficient Ethernet
      • Operating Temperature: 32° to 104°F (0° to 40°C)
      • Humidity: 10 to 90% (non-condensing)
      • General: 16 x 10/100/1000Mbps
      • Packet Forwarding Rate: 1488000pps
      • Jumbo Frame (K): 9KB
      • Dimensions (WxDxH): 17.32 x 8.66 x 1.73" (440 x 220 x 44mm)
      • Weight: 2.20Lbs (1kg)

    • Item Includes:

      • x1 GSW-1657
      • x1 Power Cord
      • x1 19" Rack Mount Kit
      • x1 Quick Installation Guide

    • GTIN:

      0878742004804
