QDCAM ME-BXC-BU100 Fiber Transmission Base Unit for RS-433 / RS-232C Communication - 3Gx4 / 12G Input - 2km Transmission

ME-BXC-BU100 - Overview

• Specifications:

  • Compatible Camera Cable: SMPTE 311 camera cable with SMPTE 304 connectors, Max. 500 m (when power is supplied to camera through the camera cable)
  • Cable Length: Max. 2000m (when local power supply is used for the camera unit)
  • Operating Temperature: 2°F - 104°F (0°C - 40°C)
  • Operating Humidity: 30% - 90% RH (Must be no condensation.
  • Weight: 3.53lbs (1.60kg)
  • Dimensions (WxDxH): 7.9" x 7.9" x 1.7" (excluding protrusions (200mm x 200mm x 42mm) - excluding protrusions
  • Power Voltage: DC 13.8V (DC 12V to 17V: when local power supply is used)
  • Power Consumption: Max. 60W (including power supply to cam-site unit and cable loss)


• Item Includes:

  • 1x ME-BXC-BU100 QDCAM Transmission System Base Unit


• GTIN:

  4562393843030
