Netgear XS512EM-100NAS 12-Port 10-Gigabit/Multi-Gigabit Ethernet Smart Managed Plus Switch

ITEM #: NG-XS512EM100NAS MFG #: NET-XS512EM-100NAS

Primary Image
  • Product Image Thumbnail 1 of 5
  • Product Image Thumbnail 2 of 5
  • Product Image Thumbnail 3 of 5
  • Product Image Thumbnail 4 of 5
  • Product Image Thumbnail 5 of 5
Free Shipping with $49 Minimum Order

List Price:

$1,361.57

Our Price:

$1,293.49

Availability: Typically Ships in 3-10 Business Days
iAvailability Description Popup


    NET-XS512EM-100NAS - Overview

    As a leading provider of network equipment for SMBs, NETGEAR understands the importance of reliable and high performance networks. With the growth of virtualization, cloud-based services and applications like VoIP, video streaming and IP surveillance, SMB networks need to extend beyond simple reliability to higher speed and performance. The 10-Gigabit and Multi-Gigabit Plus Switches from NETGEAR present the right solution for this requirement; delivering unprecedented non-blocking10-Gigabit bandwidth at the most affordable cost. All of them are perfect for removing the SMB network bottlenecks caused by the proliferation of Gigabit-to-the-desktop and the upcoming 10-Gigabit/Multi-Gigabit high end workstations.


    As cloud based services such as VoIP, video streaming, IP cameras, and other network connected equipment becomes more popular, switches like the XS512EM 12-Port Gigabit Managed Smart Cloud Switch from NETGEAR become a necessity to manage network traffic.

    Installation of the NETGEAR XS512EM switch is simple as it comes equipped with twelve 100M/1G/2.5G/5G/10G RJ-45 copper ports including two shared SFP+ ports. The rackmount form factor makes it easy to integrate the switch into existing racks. Once installed, the 240 Gb/s switching capacity, 32K MAC address table, and support for 64 VLANs and 128 multicast groups ensures the switch can offer optimal network performance even under demanding network conditions.

    • Features:

      • 5-speed Networking : - XS512EM-12-port 10-Gigabit/ Multi-Gigabit, - XS724EM-24-port 10-Gigabit/Multi-Gigabit.
      • 2 -Port SFP+ (combo) for fiber uplinks.
      • Rackmount or Desktop.
      • Internal power supply to eliminate power brick.
      • Active fans for whisper quiet operation.
      • 50°C Maximum Operating Temperature.
      • Compact Small Form Factor (XS512EM).

    • Specifications:

      • Ports 100M/1G/2.5G/5G/10G RJ45 Copper Ports
      • 12
      • SFP+ Ports
      • 2 (shared)
      • Maximum Number of Source Ports Allowed
      • 11
      • Form Factor Rackmount
      • Memory Buffer 3 MB
      • Bandwidth 240 Gb/s
      • MAC Address Database Size 32 K
      • VLAN Number of VLANs Supported
      • 64
      • Number of Link Aggregation Groups (LAGs - 802.3ad) 8 LAGs with max 8 members in each LAG
      • Multicast Group 128
      • Fans 2
      • 802.3az Support Yes
      • Power Maximum Power Consumption
      • 76.56 W
      • LEDs Power, Speed, Fan, Link/Activity
      • Acoustics 29.3 dBA
      • Operating Temperature 32 to 122°F / 0 to 50°C
      • Electromagnetic Compliance A
      • Dimensions 12.9 x 8.0 x 1.7" / 32.8 x 20.4 x 4.3 cm
      • Weight 5.54 lb / 2.51 kg
