Novastar VX4S-N Video Processor Compatible with ADJs Video Screen Products

VX4S-N - Overview

• Features:

  • Industry-standard input connectors: 1x HDMI, 1x DVI (IN+LOOP), 1x VGA, 1x CVBS, 1x DP, 1x 3G-SDI (IN+LOOP)
  • 4x Gigabit Ethernet outputs, capable of loading up to 2,300,000 pixels
  • Quick screen configuration supported Computer software for system configuration is not necessary.
  • Seamless high-speed switching and fade effect supported, to present professional-quality images
  • Adjustable PIP position and size, free control at will
  • Nova G4 engine adopted, enabling exquisite image display with a good sense of depth, without flickering and scanning lines
  • White balance calibration and color gamut mapping based on different features of LEDs used by screens, to ensure the reproduction of true colors
  • Independent external audio output supported
  • High bit-depth video input: 10-bit and 8-bit
  • Multiple device units connected for image mosaic
  • NovaStar's new-generation pixel level calibration technology adopted, ensuring a fast and efficient calibration process
  • An innovative architecture adopted, allowing for smart screen configuration
  • The screen debugging can be completed within several minutes, which greatly shortens the preparation time on the stage.


• Specifications:

  • Capacity: 2.3 Million
  • Width & Height: Max Width 3840, Max Height 1920
  • Control Port: USB/TCP/IP
  • Video Input: 1x HDMI, 1x DVI (IN+LOOP), 1x VGA, 1x CVBS, 1x DP, 1x 3G-SDI (IN+LOOP)
  • Audio Input: 3.5mm Audio port/HDMI
  • Video Format: RGB, YCrCb4:2:2, YCrCb4:2:2, YCbCr 4:2:0
  • Video Monitor: DVI out
  • Video source grayscale: 8Bit
  • Output Port: 4 Ethernet port
  • Cascading: Yes
  • Certification: CB, UL/CUL, EAC, RoHS, LVD, EMC, IC, FCC SDoC
  • Zoom: Yes
  • Splice: Yes
  • Layers: PIP
  • Preview: Yes
  • Preset: Yes


• Item Includes:

  • 1x Power cord
  • 1x USB cable
  • 1x DVI cable
  • 1x HDMI cable
  • 1x User Manual


• GTIN:

  0818651029918
