Palmer Audio PMT04 Balancing Transformer for Microphone Levels

    Questions? Ask a Markertek Expert:
    800-522-2025 Email

    Palmer Audio PMT04 Balancing Transformer for Microphone Levels

    Manufacturer: Palmer Audio

    Item #: PLM-PMT04   •   MFG #: PMT04




    Share!





    Microphone transformer with a 1:1 ratio to balance unbalanced inputs, also useful for isolating ground. Primary winding with center tap to feed in phantom power. Electrostatic and mu-metal shielding, PCB mount. Technical specifications: Ratio 1 : 1 Impedance: 200 ohms : 200 ohms Frequency range: 40 Hz - 20 kHz, +/- 0,5 dB Level: + 4 dB max. Dimensions: (without pins): 30 x 30 x 20 mm


    • Features

      • Mic transformer with 1:1 ratio + PCB mount + Frequency range 40Hz to 20 kHz

    • Specifications

      • Ratio: 1:1
      • source impedance: 200 Ohm(s)
      • load impedance: > 200 Ohm(s)
      • max. level: + 4 dB
      • frequency response: 40 - 20000 Hz
      • PCB: n.a.
      • dimensions: EE25 mm
      • application: mic balancing
